RS232/485 860mhz 960mhz UHF RFID Integrated Reader New Arrival for Storage Management
- Category: >>>
- Supplier: Shenzhen Vanch Intelligent Technology Co. Ltd.
Share on (1600930775011):
Product Overview
Description
Product Description
Specification
Product Model (Order Code) | VI-IR610P-HF | |
Performance | ||
NFC radio frequency chip | ZC100 | |
air protocol | ISO 15693 / ISO 14443A | |
working frequency | 13.56MHz | |
Reading distance | 1 ISO15693 : 110mm ISO 14443A: 60mm (depending on label) | |
Write distance | ISO15693 : 100mm ISO 14443A: 50mm (depending on label type) | |
Label RSSI | support | |
antenna | PCB integrated antenna | |
Communication Interface | RJ45 , RS232, RS485 | |
Protocol | ModbusTCP, ModbusRTU, TCP/UDP protocols | |
W i F i (optional) | Support IEEE 802.11n/b/g | |
Heating device (optional) | Low temperature automatic heating (minus 5°) is optional (determined according to the project site environment) | |
communication rate | Serial port communication rate 9600~115200bps, RJ45 communication rate 10/100 Mbps | |
working status | LED indicator light, buzzer | |
Reliable Firmware Upgrades | Scalable upgrade mechanism | |
General Purpose Input/Output (GPIO) | 2- way input, 2- way output | |
application software interface | Provide API development kit and C , C# and Java application routines | |
mechanical and electrical properties | ||
size | 95 (L)* 95 (W)* 40 (H)mm | |
power supply | Working voltageDC9~ 24V | |
power consumption | Maximum power consumption 3W, maximum starting current 1A | |
Communication Harness | Industrial connection tail wire one for five | |
weight | Approx. 1.1 kg (whole set) | |
humidity | 5% ~ 95%, non-condensing | |
degree of protection | IEC IP67 | |
Operating temperature | - 4 0ºC ~ + 85ºC _ | |
storage temperature | room temperature | |
Tips: | For more information, please consult online customer service, thank you | ||||||
Application and Cases
FAQ
Q: You are factory or trading company?
A: We are original equipment manufacturer in RFID UHF reader for over 10 years.
Q: How is your QC?
Q: How is your QC?
A: We have strict QC process and all the products will be 100% testing before shipping.
Q: What is your payment term?
Q: What is your payment term?
A: 100% payment should be paid before shipping.
Q: What is your payment way?
Q: What is your payment way?
A: T/T, Western Union, MoneyGram
Q: What is your warranty?
Q: What is your warranty?
A: within 1 year.
Q: Can I get technical support from you?
Q: Can I get technical support from you?
A: Sure. Our sales are of all good knowledge in the field. Besides, we have a technical team behind to support.
