Product Overview

Description



Products Description


Hammer Crusher is a kind of equipment that crushes materials in the form of impact Crushing the size of 100-400 mm material to 10-15m or less. Hammer mill machine can not only be used in stone crusher plant, sand plant, but also can replace the cone crusher in the mineral processing. It is suitable for small-scale crushing of stones and brittle materials below medium hardness (less than or equal to 75 tons per hour).Suitable material: Granite, Limestone, Coal etc.


Hammer Crusher
Types of hammer mill is mainly used for crushing medium-hard or brittle materials with hardness not more than 300Mpa and 15% moisture,such as coal,cement,gypsum,alumen,brick,tile,limestone,etc.It has the features of simple structure, big crushing ratio, high production efficiency, uniform particle size, etc. This equipment can be adjusted to reach various discharged granularity as the customers' requests.




Hammer crusher is the most common of stone crushing equipment. It is also called hammer mill. It has high production capacity, low energy consumption, simple structure, reliable quality, easy maintenance, etc.




Work Principle
The motor drives the rotor to rotate at high speed in the crushing chamber. The material is fed into the machine from the upper feeding port, and is crushed by the impact, impact, shearing and grinding of the high-speed hammer. In the lower part of the rotor, there is a sieve plate, and the particle size smaller than the sieve hole size in the crushed material is discharged through the sieve plate, and the coarse particle size larger than the sieve hole size is retained on the sieve plate and continues to be hit and ground by the hammer, and finally passes through the sieve plate. out of the machine.




Product Parameters


Model
Feed Size
(mm)
Output Size
(mm)
Capacity
(T/H)
Power
(KW)
Weight
(T)
PCΦ400*300
≤200
≤25
5-10
11
0.8
PCΦ600*400
≤250
≤30
10-22
22
2.26
PCΦ800*600
≤250
≤35
18-40
55
4.8
PCΦ1000*800
≤350
≤35
25-50
75
5.9
PCΦ1000*1000
≤350
≤35
30-55
90
8
PCΦ1200*1200
≤350
≤35
50-80
132-160
19.2
PCΦ1400*1400
≤350
≤35
50-100
280
32
PCΦ1600*1600
≤350
≤35
100-150
480
37.5


Product Details




Eccentric shaft adopt 40Cr steel precise forged, Advanced Movable jaw plate assemble made from high quality casting parts, Tooth-shape plate, deep V-chamber, high manganese steel material ZGMn13-4 make crusher more reliable, Precise casting heavy fly wheel,Jaw crusher frame adopt thick Q235B heavy steel plate welding process.Machine blasting, anti-rust painting, surface painting at least three times paintings.
