Openwrt Dual Band 2.4G & 5G support VPN PPTP L2TP 1200Mbps 12V 5g router for buses
- Category: >>>
- Supplier: Shenzhen Huasifei Technology Co. Ltd
Share on (1600931124672):
Product Overview
Description
Product Description
3G 4G lte router openWRT mt7621 dual core chipset with 4 external omni antennas 2.4G/5GHz dual band Office wireless wifi router
used new MT7621 wireless solution, performs better and more functions. Stable wireless performance, stronger scalability , the Max
transmission rate could be 1200Mbps (2.4G 300Mbps, 5G will be 880M(Max). Also supports 3G/4G(3G/4G MINI-PCIE module is necessary).
It could also dial-up via the USB port(should mount the 3G/4G network card. Provide 1*USB 3.0 interface, 1*Micro slot. It adopts
anti-drop 4PIN interface,DC power supply, and supports power supply (9 -36)V voltage.
Support 80.11ac / 802.11a / 802.11n / 802.11g / 802.11b network protocol, the max transmission rate could be 1200Mbps(2.4G
300Mbps+ 5G 867Mbps)
Support 802.113 / 802.11u protocol, 5* 10/100/1000Mbps Auto MDI/MDIX
USB 2.0 date interface
1 Micro TF Card Slot
Support 3G/4G(an option, need install with MINI-PCIE 3G/4G module)
Many kinds of way to protect your data transmission;
Support 11AC,dual band (an option, need install with MINI-PCIE 5G module)
bands Situation
For 3G or 4G modules, different carriers in different countries have different bands and frequencies. Please tell me the bands or frequencies. Then we can choose the right 3G or 4G modules and update the price for you.
4G AU version （Australia / New Zealand / Taiwan / Brazil）
LTE-FDD: B1/B3/B4/B5/B7/B8/B28/
LTE-TDD:B40
WCDMA: B1/B2/B5/B8
GSM: B2/B3/B5/B8
4G EU version (Europe / Middle East / Africa / Korea / Thailand)
LTE-FDD: B1/B3/B5/B7/B8/B20
WCDMA: B1/B2/B5/B8
GSM: B2/B3/B5/B8
4G EU version (Europe / Middle East / Africa / Korea / Thailand)
LTE-FDD: B1/B3/B5/B7/B8/B20
LTE-TDD:B38/B40/B41
WCDMA: B1/B5/B8
GSM: B3/B8
4G USA version （North American AT&T）
LTE-FDD: B2/B4/B12
WCDMA: B2/B4/B5
4G Global version
LTE TDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/
B19/B20/B25/B26/B28
LTE TDD: B38/B39/B40/B41
WCDMA: B1/B2/B4/B5/B6/B8/B19
GSM: B2/B3/B5/B8
GSM: B3/B8
4G USA version （North American AT&T）
LTE-FDD: B2/B4/B12
WCDMA: B2/B4/B5
4G Global version
LTE TDD: B1/B2/B3/B4/B5/B7/B8/B12/B13/B18/
B19/B20/B25/B26/B28
LTE TDD: B38/B39/B40/B41
WCDMA: B1/B2/B4/B5/B6/B8/B19
GSM: B2/B3/B5/B8
- Product Feature
* Support 80.11ac / 802.11a / 802.11n / 802.11g / 802.11b network protocol, the max transmission rate could be 1200Mbps(2.4G
300Mbps+ 5G 867Mbps)
* Support 802.113 / 802.11u protocol, 5* 10/100Mbps Auto MDI/MDIX
* 1 USB 2.0 date interface
* 1 Micro SD Card Slot
* Support 3G/4G(an option, need install with MINI-PCIE 3G/4G module)
* Many kinds of way to protect your data transmission；
* Support 11AC,dual band (an option, need install with MINI-PCIE 5G module)
Hardware Product Specification
Main Chipset
MT7621A (880MHz)
2.4G Chip set
MT7603EN
5.8G Chip set
MT7612EN
RAM
DDR3 256MB （MAX DDR2 512MB）
SPI FLASH
16MB （MAX 32MB）
Protocol
IEEE 802.11n、IEEE 802.11g、IEEE 802.11b、
IEEE802.11ac 、IEEE802.11a
IEEE 802.3、IEEE 802.3u
RT Power
802.11b 18dBm±2dBm
802.11g 15dBm±2dBm
802.11n 15dBm±2dBm
802.11a 20dBm±2dBm
802.11ac 20dBm±2dBm
Reception Sensitivity
802.11b ≦-76dBm
802.11g ≦-65dBm
802.11n ≦-61dBm
802.11a ≦-64dBm
802.11ac ≦-59dBm
MT7621A (880MHz)
2.4G Chip set
MT7603EN
5.8G Chip set
MT7612EN
RAM
DDR3 256MB （MAX DDR2 512MB）
SPI FLASH
16MB （MAX 32MB）
Protocol
IEEE 802.11n、IEEE 802.11g、IEEE 802.11b、
IEEE802.11ac 、IEEE802.11a
IEEE 802.3、IEEE 802.3u
RT Power
802.11b 18dBm±2dBm
802.11g 15dBm±2dBm
802.11n 15dBm±2dBm
802.11a 20dBm±2dBm
802.11ac 20dBm±2dBm
Reception Sensitivity
802.11b ≦-76dBm
802.11g ≦-65dBm
802.11n ≦-61dBm
802.11a ≦-64dBm
802.11ac ≦-59dBm
Work Channel
2.4G:2412 MHz-2484MHz(channel 1 -channel 14).
5.8G: 5725MHZ-5850M(channel:149、153、157、161、165)
Wireless Rate
Max 1200Mbps（depends on the 11AC mode）
Work Frequency
2.4GHz, 5.8GHz
Antenna
4* removable Omni Directional 5dBi antenna
Interface
1* PCI-E slot
1 *SIM card slot
1 *USB 2.0 port
1 *Micro SD card slot
1 *10/100M/1000M WAN port（Auto MDI/MDIX）
4 *10/100M/1000M LAN port（Auto MDI/MDIX）
LED
PWR.2G.5G.WAN.LAN1.LAN2.LAN3.LAN4
Button
Reset Button
Max Power consumption
< 12W
Dimension（L*W*H）
164*137*35MM
2.4G:2412 MHz-2484MHz(channel 1 -channel 14).
5.8G: 5725MHZ-5850M(channel:149、153、157、161、165)
Wireless Rate
Max 1200Mbps（depends on the 11AC mode）
Work Frequency
2.4GHz, 5.8GHz
Antenna
4* removable Omni Directional 5dBi antenna
Interface
1* PCI-E slot
1 *SIM card slot
1 *USB 2.0 port
1 *Micro SD card slot
1 *10/100M/1000M WAN port（Auto MDI/MDIX）
4 *10/100M/1000M LAN port（Auto MDI/MDIX）
LED
PWR.2G.5G.WAN.LAN1.LAN2.LAN3.LAN4
Button
Reset Button
Max Power consumption
< 12W
Dimension（L*W*H）
164*137*35MM
