High rate sodium battery 40140 3.V cells 15ah 5C 10C manufacturer sodium ion producers 120wh/kg scooter sodium ion battery akku
- Category: >>>
- Supplier: Shenzhen Asia Technology Co. Ltd.
Share on (1600931196010):
Product Overview
Description
40140 sodium ion cell 15.0Ah 3.0V
The 40140 sodium ion cell provided by Asiar technology adopts the layered oxide sodium ion battery technology, Using safe, long life, pollution-free, cost-effective sodium ion battery design, high life, more than 3000 cycles, DOD > 80%, suitable for electric tools, household energy storage, base stations, two-wheeled vehicles, low-speed vehicles, etc. This 40140 sodium ion cell internal resistance ≤2mΩ, high energy conversion efficiency and fast charging and discharging.
Product description
Specifications
Product Name: sodium-ion battery
Shell Material:Aluminium
Rated capacity:15.0Ah
Internal impedance:0.1~0.3mΩ
Nominal voltage:3.0V
Dimensions(L*W*H): 40*140mm
Weight:±0.3kg
Charge Voltage:3.9V
Max Continuous Discharge Current:280A(1C)
Cycle life (80%DOD):3000 cycles
Charging Temperature:-10~50°C
Discharging Temperature:-40~60°C
Note:
1. [Size] Please allow measurement differences of 1-3cm/0.39-0.79in due to manual measurement.
2. [Color] Due to the difference in the computer monitor, the color of the product may be slightly different from the picture, please understand.
3. [Quality] If you have any questions, please feel free to contact us for further assistance. Our customer service will respond to your enquiry within 24 hours.
4.[Note: Items other than the products displayed on the image are for reference only and are not included].
Basic parameters
project | Specification | condition | ||
Nominal capacity | 15Ah |
25±2℃,0.5C/0.5C, the new battery state | ||
Minimum capacity | 14.5Ah | |||
Operating Voltage | 1.5~3.95V | / | ||
Q | 3.0V | / | ||
AC internal resistance | 1.5±0.3mΩ | AC 1kHz,50% SOC,25±2℃ | ||
battery weight | 390±10g | Include outer packaging | ||
Energy Density | 115Wh/kg 255Wh/L | / | ||
Operating temperat ure | charging temperature | - 10~60℃ | No matter what charging and discharging mode the battery is in, once the battery surface temperature is found to exceed this range, the charging and discharging will stop | |
discharge temperature | -40~65℃ | |||
storage temperature | -40 ~35°C | 3month | ||
- 10~25°C | 6month | |||
cycle life | ≥2000cycles | 25±2℃,0.5C/0.5C,80% SOH | ||
Exterior | No cracks, scratches, deformation, stains, electrolyte leakage, etc. | |||
