Veterinary Ultrasound Scanner YSB5000V

Main specification
Probe element:80 elements 16 channels
Display: 10.4’ high resolution color TFT LCD
Scanning mode: convex, linear
Standard probe: 6.5MHz multi-frequency linear rectal probe
(frequency conversion scope:4.0 / 5.0 / 6.5 / 7.5 MHz)
Optional Probe: 4.0MHz rectal linear probe
(frequency conversion scope:2.0 / 2.5 / 3.5 / 5.0 MHz)
Optional probe:3.5MHz convex multi-frequency probe
(Frequency conversion scope:2.0 / 2.5 / 3.5 / 5.0 MHz)
Optional probe:6.5MHz intra-vaginal frequency conversion probe.
(frequency conversion scope:4.0 / 5.0 / 6.5 / 7.5 MHz)
Optional probe:7.5MHz frequency conversion probe.
(frequency conversion scope:5.0 / 6.5 / 7.5 / 9.0 MHz)
Optional probe:5.0MHz micro-convex frequency conversion probe.
(frequency conversion scope:3.5 / 4.5 / 5.0 / 5.5 MHz)
Scanning angle:convex probe 60°,intra-vaginal probe 135°
Body mark:1.ceneral2.Bovine, 3.Equine, 4. Canine, 5. Feline,6.cardio
Probe socket:\t1 socket, automatically identify the probe
Resolution:horizontal≤2mm,vertical≤1mm
Dead zone≤5mm（test report actually≤3mm）
Max scanning depth:≥17cm（test report actual ≥20cm）
Geometry position precision:Transversal≤10％,Longitudinal≤5％（test report actual ≤5％,
Longitudinal≤5％）
Scanning mode:B、2B、4B、B/M、M
8 grades depth adjustment under full visual field (8kinds of magnification)
Gain:0~127dB
Dynamic scope:27~90dB,visible & adjustable
Four different angles / switchable width
Gray:\t256
Imaging technique:full digital beam-composite, continuous dynamic focusing, dynamic aperture
Cine loop:256 frames
Permanent image storage: 100 frames
TGC control: near field, far field
Image processing:pre-process (continuous dynamic focus, dynamic aperture, dynamic filter）,
post-process（4 grades gamma correction）、frame correlation, black/white reversal, left/right reversal,
up/down reversal, edge enhancement, etc.
Depth hoist / local zooming
Frame frequency:30 frames/s
Measurement and analysis:
Normal measurement: distance, circumference, area(trochoid or el ipse), volume, etc.
Obstetric measurement and analysis:\tEDD and GA of Bovine, Equine, Ovine, Canine, Feline,
camel and goat.
Cardio measurement and analysis: depth, slope, heart rate, cycle
Report: OB report
Note:name, age, gender, hospital name, time, date, probe type, frequency, focus, frame correlation,
gain, dynamic scope, etc.
Battery: 2700MAh lithium battery (2 PCS) can work for more than 200 min each charge.
Weight of main unit: 2.25kg.
Puncture guide, with two approvable guiding lines whose angle and position can be adjustable.
USB port for flash disk to store images directly and for transferring image to PC (optional software
of case report process center)
Output: PAL / NTSC
Power supply:85V~242V,48V~62HZ
Energy-saving
8 kinds internal pseudo color
