Bolted Bonnet Stainless Steel Solid Wedge Gate Valve

Share on (1600935795346):


Price:$20.00 - $75.00

Quantity:


Product Overview

Description



Product Description


Wedge Gate Valve
Wedge gate valve can withstand high pressure because its sealing surface is at an angle with the vertical center line, and the sealing is good. Generally, having good corrosion resistant and abrasion resistant performance. The sealing face of the valve disc and seat is butt-welded with hard alloy, wearable, high temperature resistant, corrosive resistant and long service life. The valve body material is of variety. The packing and washer is selected according to the working conditions and can be used for any pressure, temperature and medium conditions. They widely used in power, oil, chemical, metallurgy, mining, and water treatment fields, especially in the power plant for dusting and equipment in the coal cleaning plant.




Product details


item
 gate valve
Place of Origin
China
Brand Name
SHOULONG
Model Number
DN15-DN1000
Application
General
Temperature of Media
High Temperature
Power
Manual
Media
steam,water,oil,urea,nitric acid,acetic acid
Structure
Gate
Standard or Nonstandard
Standard
color
customized
body material
WCB WC1 WC6 WC9 CF8 CF3 CF8M CF3M
stem material
2Cr13,F304,F316,F304L,F316L
sealing face material
PTFE,13Cr,Nylon
ambient temperature
-20℃-80℃
medium temperature
-196℃-600℃
working pressure
PN16,PN25,PN40,PN64
warranty
1year




Product standard


Design
standard
Structure
length
Flange
Test&inspection
Pressure-temperature
Product marking
GB/T12234
JB/T7746
JB/T79
JB/T13927-92
GB/T9131
GB/T12220


Main parts material


Valve body,Bonnet,support
Valve disc
Valve stem
Valve Seat
Sealing ring, washer
Packing
WCB
ZG1Cr18Ni9Ti
ZG1Cr18Ni12Mo2Ti
ZGCr5Mo
2Cr13
CF8
CF8M
CrMo
2Cr13
CF8
CF8M
25Cr2MoV
CF8
CF8M
CF8
coated gasket
enhanced
flexible
graphite




Packing & Delivery




Company Profile








Jiangsu Shoulong Valve Co., Ltd. was established in 1988 in Taiwan. Due to business development needs, our company expanded in 2000 and built more than 30 acres production bases in Nanjing and Wuxi of Jiangsu Province. In order to serve customers in mainland of China more conveniently, Jiangsu Shoulong Valve Co., Ltd. was set up in Nanjing in 2014,which is a comprehensive enterprise engaged in research&development, production, sales and import&export of automatic control valves. The operation center of our company is located in Nanjing and there are 13 marketing branches all over China,enjoying a high reputation in the industry.

Our company has a complete set of production and testing equipment, perfect organization and quality system and a number of high-quality professional technicians and also has passed ISO9001-2000, TRD100, CE, API6D, API607, DNV, CNS and other certification one by one . Because of our professional technical strength, accurate and reliable products, comprehensive solutions, We have been accepted by most of the users . At present, our business has been involved in power, metallurgy, minerals, automobile manufacturing, paper making, natural gas, environmental protection, petrochemical, food machinery, HVAC and many other fields. Through diligent efforts in the field of control valve, our company has established a mature marketing network and accumulated strong technical strength, and through continuous application practice and communication and cooperation with users, we designed a high-performance, low-cost products,which has been praised by the majority of users.
At present, our main products are pneumatic actuators, electric actuators, pneumatic valves, electric valves, a variety of ball valves, butterfly valves and automatic valve components.

SLV Jiangsu Shoulong Valve Co., Ltd. has a group of technicians and sales personnel with comprehensive technology, providing a series of service of sales, technical support, installation and commissioning and solving problems for the customers."Serving customers" is our aim. We will solve all of the problems under the customer's standpoint. "Quality product, professional service, reasonable price " is our greatest competitiveness.
Customer first,quality first, integrity first!
Welcome to visit Jiangsu Shoulong Valve. Let's work together to create a brilliant future.


FAQ


1. who are we?
We are based in Jiangsu, China, start from 2014,sell to Domestic Market(69.00%),South America(9.00%),North America(6.00%),Southeast Asia(6.00%),Africa(3.00%),Western Europe(2.00%),Eastern Europe(00.00%),Oceania(00.00%),Mid East(00.00%),Northern Europe(00.00%),Southern Europe(00.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Valve,Pneumatic Valve,Electric Valve,Pneumatic Actuator,Electric Actuator

4. why should you buy from us not from other suppliers?
1. Specialized in Automatic Control Valve for 30 years;
2. Engaged in research & development, production, sales, import & export of actomatic control valves;
3. Produciton bases in Wuxi which covers more than 30 acres;
4. Passed ISO9001, TRD100, CE AP16

5. what services can we provide?
Accepted Delivery Terms: FOB,CIF,EXW,DDP;
Accepted Payment Currency:USD;
Accepted Payment Type: T/T,L/C;
Language Spoken:English,Chinese,Spanish,Japanese,Portuguese,German,French,Russian
