nylon pa 6 granules Radici S RV300KN 3046 BK Polyamide 6 resin reinforced pa6 pellets raw material
nylon pa 6 granules Radici S RV300KN 3046 BK Polyamide 6 resin reinforced pa6 pellets raw material
nylon pa 6 granules Radici S RV300KN 3046 BK Polyamide 6 resin reinforced pa6 pellets raw material
nylon pa 6 granules Radici S RV300KN 3046 BK Polyamide 6 resin reinforced pa6 pellets raw material
nylon pa 6 granules Radici S RV300KN 3046 BK Polyamide 6 resin reinforced pa6 pellets raw material
nylon pa 6 granules Radici S RV300KN 3046 BK Polyamide 6 resin reinforced pa6 pellets raw material
nylon pa 6 granules Radici S RV300KN 3046 BK Polyamide 6 resin reinforced pa6 pellets raw material

nylon pa 6 granules Radici S RV300KN 3046 BK Polyamide 6 resin reinforced pa6 pellets raw material

Share on (1600935857362):


Price:$3.20 - $4.40

Quantity:


Product Overview

Description









Physical Properties
Metric
English
Comments
Density
1.36 g/cc
0.0491 lb/in³
DAM; ISO 1183
Water Absorption
5.5 %
@Thickness 2.00 mm,
Time 86400 sec
5.5 %
@Thickness 0.0787 in,
Time 24.0 hour
Immersion @ 23°C; ISO 62
Moisture Absorption
1.50 %
@Thickness 2.00 mm,
Temperature 23.0 °C
1.50 %
@Thickness 0.0787 in,
Temperature 73.4 °F
50% RH; ISO 62
Mechanical Properties
Metric
English
Comments
Tensile Strength at Break
165 MPa
23900 psi
5mm / min. DAM; ISO 527-2/1A
Elongation at Break
3.5 %
3.5 %
5 mm / min. DAM; ISO 527-2/1A
Tensile Modulus
9.50 GPa
1380 ksi
1mm / min. DAM; ISO 527-2/1A
Flexural Strength
255 MPa
37000 psi
2mm / min. DAM; ISO 178
Flexural Modulus
8.55 GPa
1240 ksi
2mm / min. DAM; ISO 178
Charpy Impact Unnotched
8.50 J/cm²
@Temperature -30.0 °C
40.4 ft-lb/in²
@Temperature -22.0 °F
DAM; ISO 179/1eU
Charpy Impact, Notched
1.20 J/cm²
@Temperature -30.0 °C
5.71 ft-lb/in²
@Temperature -22.0 °F
DAM; ISO 179/1e/A
Electrical Properties
Metric
English
Comments
Volume Resistivity
1.00e+11 ohm-cm
1.00e+11 ohm-cm
Conditioned. 500V; IEC 60093
1.00e+13 ohm-cm
1.00e+13 ohm-cm
DAM; 500V.; IEC 60093
Surface Resistance
1.00e+10 ohm
1.00e+10 ohm
Conditioned. 500V; IEC 60093
1.00e+12 ohm
1.00e+12 ohm
DAM; 500V.; IEC 60093
Thermal Properties
Metric
English
Comments
Melting Point
220 °C
428 °F
10°C/min; ISO 11357-1/-3
Flammability, UL94
HB
@Thickness 0.800 mm
HB
@Thickness 0.0315 in
Flame Spread
0.000 mm/min
@Thickness 3.00 mm
0.000 in/min
@Thickness 0.118 in
Automotive Interior; ISO 3795
Processing Properties
Metric
English
Comments
Melt Temperature
240 - 280 °C
464 - 536 °F
Injection Molding
Mold Temperature
80.0 - 90.0 °C
176 - 194 °F
Descriptive Properties
Injection Molding Injection Speed
Medium - high
