Product Overview
Description
Product Description
GNSSconfiguration | Number of channels | 1598 |
BDS | B1I、B2I、B3I, B1I、B3I、B1C、B2a、B2b | |
GPS | L1C/A,L2P,L2C,L5,L1C* | |
GLONASS | G1,G2,G3* | |
GALILEO | E1,E5b,E5a,E5 AltBoc*,E6c* | |
QZSS | L1 、L2C、 L5/ IRNSS：L5*/ SBAS：L1C/A,L5* | |
Positioning output rate | 1Hz~20Hz | |
Differential support | CMR、RTCM2.X、RTCM3.0、RTCM3.2 | |
Static format support | GNS, Rinex dual format static data | |
RTK positioning accuracy | Plane: ±(8+1×10-6D) mm (D is the distance between the measured points) Elevation: ±(15+1×10-6D) mm (D is the distance between the measured points) | |
Static positioning accuracy | Plane: ±(2.5+0.5×10¯6D) mm (D is the distance between the measured points) Elevation: ±(5+0.5×10¯6D) mm (D is the distance between the measured points) | |
DGPS positioning accuracy | Plane accuracy: ±0.25m+1ppm;Elevation accuracy: ±0.50m+1ppm | |
Initialization time | <10 seconds | |
Initialization reliability | ＞99.99% | |
IMU tilt compensation | Additional horizontal pole tip uncertainty typically less than 10mm + 0.7 mm/° tilt down to 30° IMU tilt angle：0°~60° | |
communication | NFC Communication | Realizing close range (shorter than 10cm) automatic pair between receiver and controller (controller equipped NFC wireless communication module needed) |
WiFi | 802.11b/g access point and client mode, can provide WiFi hotspot service | |
Bluetooth | BLEBluetooth 4.0 standard, support for android, ios cellphone connection | |
Wireless modem | Built-in radio, typically work range can be 8KM Radio repeater | |
I/O port | 5PIN LEMO external power port + RS232, 1 radio antenna interface, Type C , Micro SIM card | |
frequency band: | 410-470MHz | |
Protocol | SOUTH,Farlink,TrimTalk,ZHD, HUACE | |
User Interface | Buttons | One button operation |
Indicators | Four indicate lights | |
Electrical physical properties | battery | Internal Li-on, 6800mAh, 7.4V |
Power Supply | 9-25V DC, overvoltage protection | |
size | 135mm(Diameter)x84.75mm(Height) | |
weight | 0.97kg (battery included) | |
material | Magnesium aluminum alloy shell | |
Environmental characteristics | Dust and water release | IP68 standard, protected from long time immersion to depth of 1m |
Storag | -55°C~+85°C | |
Operating | -45℃~70℃ | |
Specification | ||
System | model | H6 |
operating system | Android 8.1 | |
CPU | 2.0 GHz eight-core processor | |
Memory | 3GB RAM | |
Storage | 32GB | |
Communication | Network | TDD/FDD-LTE 4G |
WiFi | 802.11b/g access point and client mode, can provide WiFi hotspot service | |
Bluetooth | V2.1+EDR/V3.0+HS/V4.1 | |
NFC | Support NFC IGRS | |
USB | Mini USB, supports OTG | |
Electrical | Battery | 7.4V, 3400mAh |
Battery life | 12 hours | |
Charging | < 4 hrs for full charge | |
Physical | size | 206mm×85mm×40mm |
Weight | 470g | |
Operating temperature | -30℃ ~ +60℃ |
