Good Condition Fast Design Construction Workshop Building Steel Structure Warehouse

Item name

Light steel structure prefabricated warehouse

Main structure

Material

Q345B, Q235B

Column and beam

Welded H section steel, Hot roll H section steel, Box column is also available, Circle column

Surface processing

Paint or hot dip galvanized

Connection

High strength bolt Grade 10.9s

Substructure

Purlin

C channel or Z channel, steel Q235B, galvanized

Angle brace

L50x4, Steel Q235B, Paint or hot dip galvanized

Cross bracing

Dia.20 round bar or L75x6 angle brace, Steel Q235B, Paint or hot dip galvanized

Tie bar

Dia.76*2.5 - 121*3 round pipe, Steel Q235B, Paint or hot dip galvanized

Purlin brace

Dia.12 round bar, Steel Q235B, Paint or hot dip galvanized

Connection

Ordinary bolt

Roof and Wall

Panel

(50mm, 75mm, 100mm, 150mm) Sandwich panel or (0.3mm – 1.2mm) corrugated GI color steel sheet

Transparent skylight

1.2mm FRP

Accessories

Sealant, self-tapping screw, rivet etc.

Edge cover

Made of color steel sheet

Gutter

Made of steel sheet thickness 0.5mm

Rainspout

PVC pipe

Others

Ventilator

Unpowered axial-flow ventilator, al fan or clerestory

Door

Pedestrian door, rolling door/sliding door/ lifting door

Window

plastic steel window, Alu. alloy window

Crane

With or without crane, ranging from 2 tons to 20 tons
