XB 8808H Syble Cost Effective Supermarket Price Checker 2D QR Code Reader Desktop Barcode Scanner
- Category: >>>
- Supplier: GUANGZHOU SYBLE CO. LTD
Share on (1600938182895):
Product Overview
Description
Product Description
XB-8808H Syble Cost Effective Supermarket Price Checker 2D QR Code Reader Desktop Barcode Scanner
Model:XB-8808H
Model Number | XB-8808H |
Performance Parameters | |
Light Sources | SXGA-W(Width1280*high1024) Ratio(5:4) |
Supported Symbologies
| 1D:EAN-8,EAN-13,EAN-13 2 add-on,EAN-13 5 add-on,ISSN,ISBN,UPC-A,UPC-E,Code11,Code 32,Code 39,Code 93,Code 128,Codabar,Industrial 2 of 5,Interleaved 2 of 5,Matrix 2 of 5,ISBT-128,GS1-128,GS1 DataBar(RSS14),GS1 DataBar Limited,GS1 DataBar Expanded. 2D:PDF417,MicroPDF417,QR-code,MicroQR, Data Matrix,QR,Aztec. |
Scan Range | 5mil(Code39) 1cm~15cm; UPC-13mil 1cm~33cm; 20mil(code39) 1cm~40cm; 20mil(QR Code) 1cm~28cm |
System compatibility | Linux,Android,Windows XP,7,8,10,MAC |
Minimum recognition accuracy | Code 39 4mil |
Barcode Type | 1d or 2d barcodes for Paper or Film;1d and 2d for screen ,like Phone tablets |
Motion tolerance | 4 meters/second |
Scan Mode | Automatic continuous reading mode |
Support Keyboard | Support Multi-Language |
Barcode output editing | Support for adding suffixes |
Print contrast | 20% |
Recognition angle range | Turn angle ±360°, elevation angle ±60°, declination angle ±70° |
Mutual Move | Led: Red and blue bi-color indicator: red light reading code, blue light power indicator. Beeper: Startup prompts, reading tips. Keys (touch keys): Key Switch and 2d barcodes. |
Interfaces | USB(Drive - Free), RS232, USB-COM |
Physical Parameters | |
Dimensions | 152mm*82mm*152mm |
Weight | 497.1g |
Material | ABS+PC |
Cable Length | 180CM(±3CM) |
Environmental Parameters | |
Operating Temperature | -20℃~55℃ |
Storage Temperature | -20℃~60℃ |
Relative Humidity | 5%~95% RH(non-condensing/non-freezing) |
Shock Resistance: | Withstands three times1 . 5 meters drops to concrete |
Waterproof and Dustproof | IP54 standard |
Ambient Ligh | 0-70000LUX |
Electrical Parameters | |
Working Voltage | DC5V |
Power | USB Interface: Standby Power 0.2mA/1W; Operating Power 0.33mA/1.65W Maximun Operating Power 0.481mA/2.405W. RS232 Interface: Standby Power 0.2mA/1W; Operating Power 0.33mA/1.65W; Maximun Operating Power 0.484mA/2.42W |
Product Feature
Features:
1. Fast and accurate in reading all 1D or 2D barcode codes.
2. Better read incomplete and fuzzy codes, very comfortable operation.
3. Self-developed decoder chip and high performance.
4. full quakeproof , water splash-proof, dustproof, antiknock design and EMI shielding.
5. Faster and accurate scanning, powerful decoding.
6. 32 bit CPU for encoding data.
Our company
Guangzhou Xunbao Electronics Technology co., LTD is located in Guanzhou. It is a high-tech enterprise that specializes in the R&D, manufacturing, supplying, and service of automatic identification products.
We are professional in manufacturing and designing barcode scanner with strong R&D team. Our team have an average of many years' working experience in barcode identification industry.
Main products cover 1D/2D barcode scanner, 1D/2D scan engine, wired/wireless scanner, product quality comply with international standard.
Our barcode scanners have been widely used in many industries, such us Auto, Electronic, and payment, etc.
Our company is developing rapidly, so we are looking for reliable and qualified partner from all over the world to open up more market.
Certifications
Certificates Approved:
ISO9001:2008, CE, ROHS, FC, DOC, IP54Waterproof Test, IEC60825 etc.
