Horizontal or Vertical mini kaplan turbine hydroelectric generator
- Category: >>>
- Supplier: Hongya Power Generating Equipment To Utilities Limited
Share on (1600938456489):
Product Overview
Description
LHorizontal or Vertical mini kaplan turbine hydroelectric generator
Product Description
| Type | Hydro turbine,Kaplan Turbine |
| Water Head | 2m - 40m |
| Power range | 50KW-20MW |
| Frequency | 50HZ/60HZ |
| Generator Voltage | 400V, 800V, 6300V, 10500V |
| Layout pattern | Horizontal or Vertical |
| Material | Stainless Steel ZG0Cr13Ni4Mo |
| Excitation | Brushless or Static excitation system |
| Lifespan | 50 years |
| Turbine Valve | Butterfly Valve, Gate Valve, Ball Valve |
| Generator Insulation | F/F |
Axial Flow Turbine/Kaplan Turbine
Axial Flow Turbine is used in hydropower plants with low and middle water head commonly ranging from 3m to 30m. It can be divided into Propeller /Fix Blade Type (ZD) and Kaplan/ Movable Blade Type (ZZ), Propeller turbine is used in the power plant whose flow varies little.
Kaplan turbine is used in the power plant with the flow varying much; its adjustable blades can change the angle automatically so that it can guarantee high efficient operation under different flow and load.
Other Product
They are used at Middle and Small Hydropower Plant or Hydropower Spot.
The rated output from 50KW to 20MW is our advantage.
Below is our business about Hydropower Plant:
1:Exploration & Design of Hydropower Plant
2:Design & Manufacture of Turbine Generator Set
3:EPC of Electromechanical Equipment (water to wire system)
4:Pre-sale Service of Hydropower Plant
5:Training Service of Hydropower Plant
6:Operation & Technical Consultant of Hydropower Plant
7:Installation and Commission Guidance
8:Maintenance Service of Hydropower Plant
