Product Overview

Description



Product Description


Product Name
XK-F113THC
Function
UAV Video Transmitter
Package
Packed in a professional shipping box


1.  Product performance description

XK-F113THC transmitter is a micro HD wireless image transmission product with low latency. Based on COFDM modulation, H. 264 compression, and AES encryption, it is capable of stable, reliable, and real-time wireless HD image transmission in the environment of high-speed movement and urban building occlusion. XK-F113THC transmitter supports non-line-of-sight transmission, with long distance, strong anti-interference ability, low transmission bandwidth, and small transmission delay; it can be widely used in public security, armed police, fire protection, water conservancy, electric power, maritime, customs, radio and television industries, the collocation with unmanned aerial vehicle (UAV) is one of the most popular application at present.


2. Features

* Non-line-of-sight transmission, long transmission distance, and strong anti-interference capability.
* HD image transmission, the highest support 1080p60.
* Low transmission delay.
* AES encryption for transmission security and reliability.
* Good RF index, high signal-to-noise ratio, and small stray.
* Transmission frequency and bandwidth are adjustable.
* Wide input voltage range, support DC8V~DC25V voltage input.
* Small size.
* Low power consumption.





3. Technical Parameters


Item
Parameter
Specification
Power
supply
Input
voltage
DC8V~DC25V, standard input DC12V
Overall
power consumption
≤18W @ 33dBm(2W)
Digital
baseband
Modulation
COFDM
Constellation
QPSK, 16QAM,
64QAM
Carrier
mode
2K
FEC
1/2, 2/3, 3/4,
5/6, 7/8
GUI
1/32, 1/16,
1/8, 1/4
RF
Tx
frequency
300MHz~800MHz
customizable, step 1MHz
RBW 40MHz @ 33dBm(2W)
RF
bandwidth
2 /3 /4 /6 /7
/8MHz
Output
power
33dBm(2W)
Adjustable
attenuator
0~31.5dB
A/V
Video source
HDMI, CVBS
Resolution
1080p60,
1080p50, 1080p30, 1080p25, 1080p24, 1080i60, 1080i50, 720p60, 720p50, 720p30,
720p25, 576p50, 480p60, 576i50, 480i60.
Video
bit rate
0.5~18.8Mbps
Audio
bit rate
32, 48, 56,
64, 80, 96, 112, 128, 160, 192, 224, 256, 320, 384Kbps
Video
encode
H.264/AVC
Audio
encode
MPEG-1 Audio
Layer 2
Serial
port
Configure
port
Standard RS232
level, baud rate 9600
Data
port
Standard RS232
level, baud rate 1200~115200
Transmission
encryption
AES128,AES256
Transmission
delay (end-to-end)
Minimum 300ms
Transmission
distance
30-50km @ 33dBm
(2W)
Temperature
range
Working
temperature
-30℃~55℃
Storage
temperature
-40℃~75℃
Physical
specification
Transmitter
size
105*80*18mm
Transmitter
weight
≤180g
Controller
size
≤72*70*13mm
Controller
weight
≤82g


4.Related products




5.Packing&Shipping:

Packing: Packed in a professional shipping box
Port: Yantian, Shekou or Hong Kong



6.Company Introduction

Shenzhen Xingkai Technology Co., Ltd. is a Global leading high-tech enterprise engaged in R&D development and production of RF wireless communication systems for the broadcast, public surveillance, and defense industries.

Our R&D team has over 20 years of professional technical experience in design, develop, build, support and delivery ot end-to-end communications&advanced networkings. The company attaches great importance to the construction of the R&D team, with a team who with extensive industry experience and accumulation in the fields of RF communication, Baseband unit, and images processing.

Our products range includes mimo mesh network, military radio, tactical radio, software detined radio, tactical data link, ip encoder, there has also been continued demand in the areas of military C2/C3/C4ISR/C5ISR mission systems, border and perimeter security systems, unmanned aircraft systems, unmanned surtace vessels, remote controlled systems, and homeland security solutions, law enforcement and also covering film, broadcast and live stream activities that who can't risk communication failure.
