Signal Amplifier Mobile Signal Repeater DCS 1800MHz WCDMA 2100MHz 4G Signal Amplifier Repeater
- Category: >>>
- Supplier: Hangzhou Shengtong Technology Co. Ltd.
Share on (1600940691669):
Product Overview
Description
Product Features
Features：
1. Support Muti-Carriers, Ideal for Muti-operators In-building solution.
2.Use of wideband high linearity and low intermodulation amplifier, to ensure strong signal input of the linear
output.
3. Very low system noise can be connected multiple inline boosters in parallel.
4. Digital intelligent automatic synchronization with donor BTS.
5. Integrated FDD-LTE 1800/WCDMA (UMTS2100) modem with OMT software. Support optional OMC
remote management system (NMS).
2.Use of wideband high linearity and low intermodulation amplifier, to ensure strong signal input of the linear
output.
3. Very low system noise can be connected multiple inline boosters in parallel.
4. Digital intelligent automatic synchronization with donor BTS.
5. Integrated FDD-LTE 1800/WCDMA (UMTS2100) modem with OMT software. Support optional OMC
remote management system (NMS).
6. Optional backup battery and multiple power supply choices available (AC/DC/Solar Power).
Specification
Item | Specification | ||||
Uplink | Downlink | ||||
Frequency Range (MHz) | GSM900 Band | 890-915 | 935-960 | ||
GSM/LTE FDD1800 Band | 1710-1785 | 1805-1880 | |||
WCDMA2100 Band | 1920 -1980 | 2110-2170 | |||
Max. Total Output Power( Center Frequency ) (dBm) | 23±2 | 33±2 | |||
Gain (dB) (Center Frequency) at 25℃ | 80±3 | 80±3 | |||
ATT Adjustable Error (dB) | ≤ |±1.5| | ≤ |±1.5| | |||
ATT Adjustable Range (dB)/(Step) 1dB | 0~30 @ 1 dB step | ||||
ALC (dB) | 0~25 | ||||
Noise Figure (dB) (Max. Gain) | ≤ 7.0 | ≤ 7.0 | |||
Input / Output VSWR(Power up, Min Gain, Pin=-30dBm) | ≤ 1.8 | ≤ 1.8 | |||
Time Delay (us) | ≤ 5.0 | ≤ 5.0 | |||
Temperature Range (℃) | -25 ~ +55 | ||||
Humidity Range (%) | 5~95 | ||||
Dimension (mm) | 450*315*181 MM | ||||
Power Supply | AC176-264V | ||||
Company Profile
Hangzhou Shengtong Technology Co,. Ltd
Hangzhou Shengtong Technology Co.,ltd , Is A Certified ISO9001-2015 Company Located In Hangzhou Were Founded In 1999.
There Is Well Educated Management Team And Also Experienced Engineers Major In Microwave Technology. It Is Specialize In The Products Including, Comprehensive Mobile Enhancement Solutions, All Kinds Of Repeater, Rf Components, Antenna,Subassembly To Help To Optimize Operators’ Mobile Networks
Certifications
Product Categories
About Us
FAQ
Q:What're the main products of CenRF?
A: CenRF specializes in manufacturing all types of communication products. Our main products are repeaters, antennas, power splitters, couplers, combiners, cables, and connectors.
A: CenRF specializes in manufacturing all types of communication products. Our main products are repeaters, antennas, power splitters, couplers, combiners, cables, and connectors.
Q: Can your company provide Technical Support?
A: Yes. We have experienced technical experts who are willing to help you deal with technical problems.
A: Yes. We have experienced technical experts who are willing to help you deal with technical problems.
Q: Do you test the equipment before your delivery?
A:Yes. We do test every component after installation to ensure we've delivered the signal solution you needed.
A:Yes. We do test every component after installation to ensure we've delivered the signal solution you needed.
Q: Do you have OEM&ODM service?
A: Yes, we can support our customers specialled products and we are able to put your logo on the products.
A: Yes, we can support our customers specialled products and we are able to put your logo on the products.
Q: Can your company provide CO or Form E certificate?
A: Yes, we can provide it if you need.
A: Yes, we can provide it if you need.
Q：Can your company provide solutions?
A：Yes. Our team of IBS experts will help find the most cost-effective solution for your application.
A：Yes. Our team of IBS experts will help find the most cost-effective solution for your application.
