High quality aluminum wedding tent with air conditioner for sale

Product Overview

Description

high quality aluminum wedding tent air conditioner for sale

Product Description



1)Application:

High quality aluminum wedding tent with air conditioner for sale  (BS series, A frame) can be widely used as the wedding tent, party tent, exhibition tent, conference tent, different kinds of festivals tent, hajj tent, corporate events tent, sports tent, & temporary, semi-permanent or permanent building purpose etc.

2)Materials:
Fabric: Double PVC coated polyester fabric, 650-900g/sq. m, water proof, UV resistance, anti-mildew, self-cleaning, fire retardant according to standard NFPA701 & DIN4102 B1/M2



3)Frame:

Hard pressed extruded aluminum 6061/T6, anodized surface finishing.

Main frame profile size: 204*120*4mm ;



4)Connections:

Hot-dip galvanized steel;



5)Life span:

Life span of fabric(cover & sidewalls): 8-10years;

Life span of aluminum frame: 20-30years



6)Structure safety parameters:

Wind load: 100km/h (0.5kn/M2)

Snow load: 25kg/sq.m



7)Color available:

White, red, yellow, blue, green, black, grey, transparent etc





Specification for wedding tent air conditioner     (BS series, A frame), pls refer to chart:

Type	Span (m)	Side height (m)	Ridge height (m)	Bay Distance (m)	Roof Pitch	Longest Component (m)	Wind Load (km/h)
BS10/4-5	10	4	5.5	5	18°	6	100
BS15/4-5	15	4	6.4	5	18°	8.5	100
BS20/4-5	20	4	7.1	5	18°	10.7	100
BS25/4-5	25	4	7.9	5	18°	10.7	100



Main frame Profile	204x120x4mm(4-channel)
Eave Connection	Hot-dip Galvanized Twin Steel Plate
Roof Fixing	Bar Tension
Frame Material	Hard Pressed Extruded Aluminum 6061/T6
Cover Material	Double PVC coated Polyester textile, flame retardant to DIN4102 B1,M2,650-900g/sq.m



The Technical Date for wedding tent air conditioner:



*Specialized in Producing different sizes of tents  base on unique requirements

*For more information: www.superbtent.com
