MECHANICAL DATA | ||||||
Module Dimensions | 2278*1134mm*35mm | |||||
Weight | 28.5kg | |||||
Glass | Single glass, 3.2mm coated tempered glass | |||||
Junction-Box | Split junction box, IP68, 3 diodes | |||||
Cables | 4mm2, positive 400 / negative 200mm, length can be customized | |||||
Cell Orientation | 144cells(6*24) |
ELECTRICAL CHARACTERISTICS | ||||||||
Minimum performance at standard test conditions, stc1 (power tolerance 0~+5w) | ||||||||
Model | LR5-72HTH-570 | LR5-72HTH-575 | LR5-72HTH-580 | LR5-72HTH-585 | ||||
Max. Power | 570 | 575 | 580 | 585 | ||||
Open Circuit Voltage | 51.91 | 52.06 | 52.21 | 52.36 | ||||
Short Circuit Current | 14.07 | 14.14 | 14.20 | 14.27 | ||||
Max. Power Voltage | 43.76 | 43.91 | 44.06 | 44.21 | ||||
Max. Power Current | 13.03 | 13.10 | 13.17 | 13.24 | ||||
Efficiency² | 22.1 | 22.3 | 22.5 | 22.6 |
