China First Top Down DLP 3D Printer DM200 Printing Size 192*108*120mm For Dental Applications

Product Overview

Description

Pinter  Parameter

Product Model		DLP-DM200
Printing Size		192*108*120mm
Z Axis Accuracy		0.002mm
Net Weight (Without Material)		65KG
Printing Speed		6-8 second/layer
Printing Technology		Top-Down DLP
Light Source		4K,405nm Light Source DLP
Connection Type		USB Stick
Machine Size (L*W*H)		570*480*800mm
Layer Thickness		0.03-0.15mm
XY Resolution		50um
Power Supply		220V/50HZ
Slicing Software		VoxelDance Tango
Operating Screen		7.0"Resistive Screen
Operating System		Zongheng Embedded System
Printing Platform		Magnetic detachable platform
Import File Format		igs,stl,step
Coating system		Adjustable negative pressure scraper
Warranty		One Year
Tank Capacity		5L(6KG)
Resin		405nm:Model Resin, Dental Resin, Flexible resin, Jewelry Resin, High Temperature Resin, High ToughnessResin,Water Washable Resin,Transparent Resin





1. SuperMaker DM200 is DLP 3d printer developed for model resin and ceramic printing, open style, easier to adjust.
2. Suitable Projector modes: 405nm or 385nm.
3. We have created unique testing function for material testing. Do not need complex operations. Supports single-layer exposure of specified models. Parameters can be modified directly on the touch screen, and a set of curing parameters can be tested in one minute. With just a few milliliters resin, simple models can be printed to test performance.
4. It supports stl, igs, step file.
5. Scrapers: two kinds of working model, one is for without coating and pressure, use for the high sticky resin, such as ceramic resin, another one is with coating and pressure, use for normal model resin etc.
6. Equiped with various tanks with different sizes. Users can customize the tank.
