Dryer Starch Powder drum dryer for Beer active dry yeast rotary drum scraper dryer Sweet Potato Drying Machine
- Category: >>>
- Supplier: Zhengzhou Great Machinery Equipment Co. Ltd.
Share on (1600945599096):
Product Overview
Description
Products Description
Scraper dryer is an internal heating conduction type rotary continuous drying equipment. The rotating drum passes through the lower chute and adheres to a film of thickness. The heat is transported through the pipe to the inner wall of the drum, to the outer wall of the drum, and then to the feed film, so that the humidity in the film is evaporated and dehumidified. Dry the moisture content of the material. The dried material is placed on the surface of the drum scraper shovel away from the drum to the screw conveyor placed under the scraper, the dry material is concentrated and packaged by the screw conveyor.
Specification
Model | Hrating Area | Capacity/h | Power/kw | Weight/kg | Sizes L*W*H/mm | Consumption/kg/h | |
HG-600 | 1.12m² | 40-70kg | 2.2 | 850 | 1700*800*1500 | 100-175/steam | |
HG-700 | 1.65m² | 60-90kg | 3 | 1210 | 2100*1000*1800 | 150-225/steam | |
HG-800 | 2.26m² | 90-130kg | 4 | 1700 | 2500*1100*1980 | 225-325/steam | |
More models | 130-1575 | 5.5-18.5 | 2100-6150 | pls contacts | 325-1575 | ||
Application Range
It is suitable for drying liquid raw material or sticky material in chemical industry, dyestuff industry, foodstuff industry and so on.
Product Features
1.High thermal efficiency. Because the heat transfer mechanism of the drum dryer is heat conduction, the heat transfer direction is consistent throughout the rest of the operation cycle. Except for the cover heat dissipation and heat radiation loss, the heat is all used for the evaporation of the wet film of the film, and the thermal efficiency can reach 80%~90%.
2.The operation is flexible and wide in applicability. Many drying factors can be adjusted for the drum dryer. For example, the concentration of the feed, the thickness of the coating film, the temperature of the heating medium, the rotation speed of the drum, etc., can change the drying efficiency of the drum dryer, and many factors are not involved. This brings great convenience to the drum drying operation, so that it can adapt to the drying of various materials and different production requirements.
2.The operation is flexible and wide in applicability. Many drying factors can be adjusted for the drum dryer. For example, the concentration of the feed, the thickness of the coating film, the temperature of the heating medium, the rotation speed of the drum, etc., can change the drying efficiency of the drum dryer, and many factors are not involved. This brings great convenience to the drum drying operation, so that it can adapt to the drying of various materials and different production requirements.
3. Drying time is short. The drying cycle of the material is generally only 10-300 seconds, which is more suitable for heat
sensitive materials. If the drum dryer is placed in a vacuum, it can be operated under reduced pressure.
4. The drying rate is large. Since the coating film is thin on the wall of the cylinder, generally 0.3-1.5mm, and the heat
transfer and mass transfer directions are the same, and the surface of the film can maintain the evaporation strength of 100-150kg
H2O/m2.h.
sensitive materials. If the drum dryer is placed in a vacuum, it can be operated under reduced pressure.
4. The drying rate is large. Since the coating film is thin on the wall of the cylinder, generally 0.3-1.5mm, and the heat
transfer and mass transfer directions are the same, and the surface of the film can maintain the evaporation strength of 100-150kg
H2O/m2.h.
Packing and Shipping
Our products are multi-layered packaging, and finally packed in wooden boxes to ensure that the machine will not be damaged.Customers are very satisfied after receiving the goods, and many customers praise our machine packaging is very professional.
Company Profile
Great Machinery Equipment (zhengzhou) Co., Ltd.
2007 sees the company growth and its business scope enlarge from drying machine to a complete production line, such as washing machine, cutting machine, and packaging machine. sales and service with total investment of 5 hundred million . We mainly supply a whole production chain of closely related machines, including, cleaning machine, stripping machine, drying machine and packing machine.
2007 sees the company growth and its business scope enlarge from drying machine to a complete production line, such as washing machine, cutting machine, and packaging machine. sales and service with total investment of 5 hundred million . We mainly supply a whole production chain of closely related machines, including, cleaning machine, stripping machine, drying machine and packing machine.
FAQ
1.Are you manufacturer or trader? Where are your factory located?
We are manufacturer and we are located in Henan,China.and we can provide the competitive price and good quality.
2.Do you have OEM service? Do you provide parts?
Yes, we will, as long as you provide us with your drawings and detailed requirements.
3.How can we visit your factory?
You can fly to Zhengzhou airport, or if you arrive in Shanghai, you can tell us your specific location. We will arrange a driver to pick you up.
4.How to transport equipmen?
We usually choose sea transportation. Laboratory models can be shipped by air according to customer requirements.
We are manufacturer and we are located in Henan,China.and we can provide the competitive price and good quality.
2.Do you have OEM service? Do you provide parts?
Yes, we will, as long as you provide us with your drawings and detailed requirements.
3.How can we visit your factory?
You can fly to Zhengzhou airport, or if you arrive in Shanghai, you can tell us your specific location. We will arrange a driver to pick you up.
4.How to transport equipmen?
We usually choose sea transportation. Laboratory models can be shipped by air according to customer requirements.
5.what is your after-sales service?
We provide the English manual of the equipment manual. If you need, we will send an engineer to install and train workers.
We provide the English manual of the equipment manual. If you need, we will send an engineer to install and train workers.
