Mt7981b Chipset Openwrt Dual Band Gigabit Wifi6 Ax3000 802.11ax High Quality Wireless Router
- Category: >>>
- Supplier: Shenzhen Huachuangyilian Electronics Co. Ltd.
Share on (1600947448274):
Product Overview
Description
Mt7981b Chipset Openwrt Dual Band Gigabit Wifi6 Ax3000 802.11ax High Quality Wireless Router
Simple Introduction
HC-ZW300 is a wireless dual-band Wi-Fi6 router with a transmission rate of 3000Mbps. It adopts MT7981BA +MT7976CN+MT7531AE chipset, dual-core CPU with a main frequency of 1.3GHZ, supports the latest 802.11ax
Wi-Fi technology, and provides a speed of up to 574+2402Mbps. 2 times that of ordinary Wi-Fi5, simultaneous dual-band technology to avoid interference, providing users with faster downloads, smoother video and online gaming experience, and compatible with 802.11b/g/a/n/ac/ax mixing equipment. It also adopts MIMO wireless signal multi-channel technology, four channels of wireless transmission and reception at the same time, and also supports Easy-Mesh networking, which can meet the wireless coverage of multi-room, duplex and other large apartments, small
multi-offices, etc. Enjoy wireless networking experience in the corner, compatible with all mainstream smart phones, tablets, PCs and other digital products, making networking smoother and more stable.
multi-offices, etc. Enjoy wireless networking experience in the corner, compatible with all mainstream smart phones, tablets, PCs and other digital products, making networking smoother and more stable.
Product Feature
* 1 10 /100M /1000M Ethernet (WAN) interface
* 3 10 /100M /1000M adaptive Ethernet (LAN) interface, and supports automatic MDI / MDIX
* Support automatic adjustment of wireless transmission rate
* Support 2.4G and 5G Dual frequency band
* 64/128 support B i t WEP Encryption, WPA -PSK, WPA2-PSK, WPA/WPA2-PSK, WPA3-SAE, WPA2-PSK/
WPA3-SAE encryption and security mechanisms can ensure the security of data transmitted in wireless networks
* Four external non- removable high- gain antennas
* SSID support Broadcast control, effectively prevent SSID broadcast leak
* Built-in Network Address Translation (NAT) capability
* Built-in DHCP server
* WEB Software upgrade, free to use the latest software of the router
* Web- enabled management, easy installation wizard
* Support WMM to make your voice and video smoother
* Support VPN Penetrate
* Support UPnP
* Support relay function
* DMZ support
* 3 10 /100M /1000M adaptive Ethernet (LAN) interface, and supports automatic MDI / MDIX
* Support automatic adjustment of wireless transmission rate
* Support 2.4G and 5G Dual frequency band
* 64/128 support B i t WEP Encryption, WPA -PSK, WPA2-PSK, WPA/WPA2-PSK, WPA3-SAE, WPA2-PSK/
WPA3-SAE encryption and security mechanisms can ensure the security of data transmitted in wireless networks
* Four external non- removable high- gain antennas
* SSID support Broadcast control, effectively prevent SSID broadcast leak
* Built-in Network Address Translation (NAT) capability
* Built-in DHCP server
* WEB Software upgrade, free to use the latest software of the router
* Web- enabled management, easy installation wizard
* Support WMM to make your voice and video smoother
* Support VPN Penetrate
* Support UPnP
* Support relay function
* DMZ support
HC-ZW300 Datasheet
Processor | MT79781B Dual Core CPU, 1.3GHz main frequency |
WIFI chipset | MT7976CN+MT7531AE, IEEE 802.11n/g/b/a/ac/ax, max speed up to 3000Mbps |
Flash/RAM | 128MB/256MB |
Protocol standard | IEEE 802.11b, IEEE 802.11g, IEEE 802.11a, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.3, IEEE 802.3u, IEEE 802.3x |
WAN/LAN | 1* 10 /100M / 1000M WAN port, supports Auto MDI/MDIX 3* 10/100M / 1000M LAN mouth, support Auto MDI/MDIX |
Button | MESH (press for 1 second) Reset (press and hold for 5 seconds) |
LED | Three-color LED: green, red, blue |
Antennas | 4* External omni directional 5dBi gain non-removable antenna |
Basie Function | Wireless enable / disable SSID broadcast enable / disable Channel selection: 1 ~ 13 (2.4G) 36 ~ 48 + 149 ~ 165 (5GHz) 2.4G bandwidth: 20MHz ,40MHz 5G bandwidth: 20MHz ,40MHz ,80MHz |
2.4G Frequency | 2412 ~ 2472MHz |
5.8G Frequency | 5180~ 5240MHz 5745MHz ~5825MHz |
Wireless Rate | 2.4G 2TR up to 574Mbps 5G 2T2R up to 1201Mbps |
2.4G Wifi Power | 2.4G actual power: 802.11b 2 2 ±1.5dBm 802.11g 21±1.5dBm 802.11n20 19±1.5dBm 802.11n40 19±1.5dBm 802.11ac40 17.5±1.5dBm 802.11ax40 17.5±1.5dBm |
5.8G Wifi power | 802.11a 19±1.5dBm 802.11n20 18.5±1.5dBm 802.11n40 18.5±1.5dBm 802.11ac80 17.5±1.5dBm 802.11ax80 16.5±1.5dBm |
Operation Mode | AP Router Repeater |
Antennas | 4* External omni directional 5dBi gain non-removable antenna |
Wireless Security | Wireless MAC address filtering 64/128bit WEP encryption WPA-PSK, WPA2-PSK, WPA3-SAE, WPA/WPA2-PSK, WPA2-PSK/WPA3-SAE |
Other Feature | Wireless host status display Wireless site scan Seamless roaming between nodes Seamless roaming between frequency bands |
Wifi Setting | Wi-Fi basic settings (dual frequency integration, switch, wireless mode, SSID, PWD, encryption algorithm, channel, bandwidth, power adjustment) Advanced Settings (Wireless Client Isolation, 802.11h, WMM Multimedia Acceleration) Multi- SSID (SSID, encryption method, PWD, encryption algorithm) |
Mesh Properties | Mesh switch, Role selection, Networking mode, Mesh-top |
Network Setting | Support WAN port connection type: PPPOE, dynamic IP, static IP MAC address clone, IPV6 settings, Radvd settings, IPTV settings, IGMP settings |
LAN Setting | DHCP server settings Manage IP settings |
Virtual Server | Firewall Settings, Port Forwarding, UPnP, DMZ |
Advanced Settings | Traffic statistics, D DNS settings, QoS settings, VPN settings, anti- rubbing network |
System Management | System status, E -OS setting, time setting, password management, configuration management, firmware upgrade, scheduled restart, system log |
System Tools | Traffic Statistics System log time zone setting Local WEB management control configuration File import and export Web software upgrade |
Work Environment | Operating temperature：0 ℃ to 40 ℃ Storage temperature: -40 ℃ to 70 ℃ Working humidity: 10% to 90%RH non-condensing Storage humidity: 5% to 90%RH condensation |
Certifications
All of our products have passed CCC, CE, FCC, ROHS certificates, support different countries customer's needs.
Company Profile
Shenzhen Huachuangyilian Electronics Co.,Ltd. is a professional wireless network and telecommunication equipment developer and manufacturer, we have a professional production factory around 20,000 square metes and a team of more than 100 R&D engineers.
We provide high quality wireless network and telecommunication equipment products, including 5G/4G LTE Wifi Router, Vehicle Router, AP/CPE, 4G Outdoor Router, 4G Wingle, 5G/4G Mifi, 5G/4G Module etc., ODM&OEM service is available.
We build a long term cooperation with Mediatek, Qualcomm and Realtek, capably offering good quality product and offer a good after sell service. Until now we have exportated to over 40 countries and regions.
Our vision are providing best service to customers.
We provide high quality wireless network and telecommunication equipment products, including 5G/4G LTE Wifi Router, Vehicle Router, AP/CPE, 4G Outdoor Router, 4G Wingle, 5G/4G Mifi, 5G/4G Module etc., ODM&OEM service is available.
We build a long term cooperation with Mediatek, Qualcomm and Realtek, capably offering good quality product and offer a good after sell service. Until now we have exportated to over 40 countries and regions.
Our vision are providing best service to customers.
FAQ
1) Q: Can I have a sample order?
A: Yes, welcome to place sample order order testing and checking, mixed samples are acceptable.
2)Q: What about lead time?
A: Sample needs 1-3 working days mass production time needs 3-5 weeks pased on order quantity.
3) Q: Do you have any MOQ limit?
A: Low MOQ 1pcs for sample checking are available.
4) Q: Do your products meet our standards?
A: Yes, almost all our products have CE FCC etc.
5) How to proceed an order?
A: Firstly let us know your requirements or application. Secondly we quote accourding to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for format order. Then we arrange production.
6) How do you ship the goods? How long does it take to arrive?
A: We usually ship by All Logistics, DHL, UPS, Fedes, TNT, EMS, SF Express or your designated forwarder. It usually takes 3-7 days to arrive. Air shipment and sea shipment are optional.
7) What is your payment term?
A: We have All pay, T/T, Visa, West Union, Credit Card payment terms options, you can chooe the one which is convenient or effective for you.
8) Can you customizated logo or packaging?
A: Yes, OEM/ODM are acceptable. Our design team help you design as your requirement.
A: Yes, welcome to place sample order order testing and checking, mixed samples are acceptable.
2)Q: What about lead time?
A: Sample needs 1-3 working days mass production time needs 3-5 weeks pased on order quantity.
3) Q: Do you have any MOQ limit?
A: Low MOQ 1pcs for sample checking are available.
4) Q: Do your products meet our standards?
A: Yes, almost all our products have CE FCC etc.
5) How to proceed an order?
A: Firstly let us know your requirements or application. Secondly we quote accourding to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for format order. Then we arrange production.
6) How do you ship the goods? How long does it take to arrive?
A: We usually ship by All Logistics, DHL, UPS, Fedes, TNT, EMS, SF Express or your designated forwarder. It usually takes 3-7 days to arrive. Air shipment and sea shipment are optional.
7) What is your payment term?
A: We have All pay, T/T, Visa, West Union, Credit Card payment terms options, you can chooe the one which is convenient or effective for you.
8) Can you customizated logo or packaging?
A: Yes, OEM/ODM are acceptable. Our design team help you design as your requirement.
