BW160/10 horizontal drilling mud pump drill machinery triplex double action mud piston pump for sale
- Category: >>>
- Supplier: Zhengzhou Wode Heavy Industry Co. Ltd.Zhengzhou Ltd.
Share on (1600948755345):
Product Overview
Description
Product Description
BW Series Slurry Pump is one of the principal equipment for geological drilling. It delivers the enough volume circulating mud water of desired characteristic under pressure into the well to bring the rock clastic up to the ground, to cool the drill bit to lubricate the drill tool and protect the wall of the well. So the function of the mud pump affects the efficiency of dilling and safety in production directly.
Technical Data
Model | Max.Flow | Max.Pressure | Input Power | Suction Pipe Diameter | Discharge pipe Diameter | Weight | Size(mm) |
BW80/3 | 80L/Min | 3Mpa | 5.5kw | 38mm | 25mm | 205kg | 1220*590*550 |
BW100/5 | 100L/Min | 5Mpa | 18.5kw | 76mm | 38mm | 700kg | 2250*750*1770 |
BW150 | 150L/Min | 7Mpa | 7.5kw | 51mm | 32mm | 560kg | 1840*795*995 |
BW160H | 160L/Min | 1.3Mpa | 5.5kw | 51mm | 32mm | 130kg | 850*600*450 |
BW160/10 | 160L/Min | 10Mpa | 11kw | 51mm | 32mm | 430kg | 1450*745*970 |
BW200/4 | 200L/Min | 4Mpa | 15kw | 76mm | 51mm | 300kg | 1050*630*820 |
BW240/10 | 240L/Min | 10Mpa | 15kw | 51mm | 32mm | 430kg | 1450*745*970 |
BW250 | 250L/Min | 7Mpa | 15kw | 76mm | 51mm | 650kg | 1560*995*650 |
BW320 | 320L/Min | 10Mpa | 30kw | 76mm | 51mm | 720kg | 1905*1100*1200 |
BW350/13 | 350L/Min | 13Mpa | 45kw | 76mm | 51mm | 760kg | 1850*1050*1230 |
BW400/10 | 400L/Min | 10Mpa | 45kw | 76mm | 51mm | 720kg | 1905*1100*1200 |
BW450 | 450L/Min | 2Mpa | 18.5kw | 89mm | 51mm | 540kg | 1350*820*1040 |
BW450/5 | 450L/Min | 5Mpa | 22kw | 76mm | 51mm | 520kg | 1000*995*650 |
BW500/10 | 500L/Min | 10Mpa | 45kw | 89mm | 51mm | 1200kg | 1455*890*1230 |
BW600/10 | 600L/Min | 10Mpa | 55kw | 89mm | 51mm | 1400kg | 1500*890*1230 |
BW750 | 750L/Min | 6Mpa | 45kw | 89mm | 51mm | 1400kg | 1500*890*1230 |
BW850/2 | 850L/Min | 2Mpa | 37kw | 127mm | 64mm | 1500kg | 2000*1030*1400 |
BW850/5 | 850L/Min | 5Mpa | 90kw | 152mm | 64mm | 3100kg | 3018*1120*2050 |
BW series Mud Pump Advantage
1. Multi-speed shift gears for variable displacement.
2. Lightweight structure, easy to move.
3. Easy to operate.
2. Lightweight structure, easy to move.
3. Easy to operate.
Product Application
BW series mud pump is widely used to transfer water, mud, and other flushing fluids when drilling in water well, and oil and gas well areas, such as mining, drilling, coal, railway, highway, water conservancy, hydropower, and bridges. It can be also used for high-rise buildings, and foundation reinforcement works.
Related Product
Contact Us
We have many different models for your option, if you are interested in our mud pump or other related pump, welcome to send inquiry to us.
Before we send quotation, please let me know the following questions:
1. What is the pressure and flow you need? (Or what's your hole diameter and hole depth?)
2. Do you need electric motor driven or diesel engine driven or hydraulic motor driven?
3. If you need electric motor driven, the voltage in China is 3 phase 380V 50Hz, is it ok for you?
Packaging&Shipping
Company Information
Wode Heavy Industry Co. Ltd., short name Wodetec, is a manufacturer specializing is R&D, manufacturing and sale of mud pump.
We have developed the BW series of mud pumps and other series of mud pump, electric motors, diesel engines and hydraulic motors are available options for customization. From years of experience Wode Heavy Industry Co., Ltd. has developed its own R&D and technician teams, which supports further development and customized service for clients.
We also produce grouting equipment, grout pumps, refractory mixer, refractory gunite machines, foaming machines, concrete pumps, hose pumps and a series of products.
We have developed the BW series of mud pumps and other series of mud pump, electric motors, diesel engines and hydraulic motors are available options for customization. From years of experience Wode Heavy Industry Co., Ltd. has developed its own R&D and technician teams, which supports further development and customized service for clients.
We also produce grouting equipment, grout pumps, refractory mixer, refractory gunite machines, foaming machines, concrete pumps, hose pumps and a series of products.
If you are interested in our products, please contact us. Of course, you are welcome to visit our factory.
