Special Perfect Circular Intelligent Booth Digital Signage Mirror Android System Display 23.6inch 1280x1280 digital signage
- Category: >>>
- Supplier: Shenzhen Huizhongsheng Technology Co. Ltd.
Share on (1600949432736):
Product Overview
Description
Product Description
Specification
Android System hardware configuration | ||
Main chip model | RK3288 | |
Central processing unit (CPU) | 1 Cortex-A171.8GHz | |
Image Processor (GPU) | Mali-T764 | |
Running memory (RAM) | 2GB | |
System Memory (ROM) | 8GB (16G, optional, 64GB max supported) | |
The kernel version | Above the Android 5.0 | |
Other functions | Customized circular UI operation interface | |
Customized boot animation (can be modified according to customer requirements) | ||
Customized circular gallery, video player, resource manager and other operation interfaces | ||
Support the automatic switch machine setting | ||
Support for wireless Wi-Fi, wired LAN | ||
Support for USB automatic video playback | ||
Support the OTG debugging function | ||
Support for HDMI, and video output | ||
Supports a 5-point capacitive touch | ||
Main board input / output interface | ||
USB import | 2 (Type-A USB2.0 x2) | |
Audio output | 1 Road analog headset | |
Extended storage | 1-way (standard socket for TF card) | |
Network input | The v 1-way standard RJ 45 wired Ethernet port | |
V. v 1 road wireless 2.4 G Wi-Fi | ||
Sim card slot | 1-way SIM card slot (support 3G / 4G module optional) | |
Video monitor 525 vidicon video out | 1-way HDMI OUT | |
Display performance parameters | ||
Product model | JH236A02 | |
Product size | 23.6 Inch | |
Display dimensions (mm) | 600.384（H ）x 600.384（V ） | |
Physical resolution | 848 x 848 | |
Dot pitch (mm) | 0.708（H ）x0.708（W ） | |
Peak brightness of the whole machine | 700cd/㎡±50 | |
Dynamic contrast | 4000:01:00 | |
Viespective (H / V) | 178°/178° | |
Show color | 16.7M （8bit ） | |
Refresh rate | 60Hz | |
Response time | 8ms | |
Touch technology | Capacitive touch | |
Electrical performance of the whole machine | ||
Power input | AC 220V ~50Hz | |
Power supply hard switch | support | |
Power consumption (excluding 4G module) | ≥55W | |
Speaker power | 2x2W (rated power) | |
Way to install | hanging | |
Case material | Profile frame + sheet metal back plate | |
Appearance color | Mirror silver glass screen print + rose gold profile frame + black sheet metal back plate | |
working temperature | 0-50℃ | |
Working humidity | 10-90% RH (not condensing) | |
Storage temperature | -10-60℃ | |
Store humidity | 10-90% RH (not condensing) | |
Structural dimensions (in mm) | ||
Product model | JH236A01 | |
Form size of the whole machine | Ф 681mmxH51mm | |
(Long, high and thick) | 62cm*62cm*8cm | |
Bare net weight (KG) | ≤12 | |
Gross weight (KG) | ≤15 | |
Wall frame size | L500xW470xT1.5 | |
Wall hanging hole size | Horizontal 200 x vertical 200 | |
Packing list | ||
Round screen Android all-in-one machine | 1 | |
Wall mounted board | 1 | |
Wall hanging screws | 1 Package | |
National standard power supply line | 1 | |
Packing & Delivery
1pc/box
