High Quality Chimney Fans dc 12volt 40x40x20 mm 4020 40mm cooling fan Chimney Fans For Industrial
- Category: >>>
- Supplier: Zhoukou Baocheng Electronic Technology Co. Ltd.
Share on (1600950444832):
Product Overview
Description
Products Description
Type | Centrifugal Fans Blowers | ||||||
Dimensions | 40mm x 40mm x 20mm | ||||||
Model | MK4020 | ||||||
Specifications options | AS,RD,FG,PWM,Temperature Control ,IP56,IP68 | ||||||
Norminal Diameter Ranges | 30mm - 136mm ; | ||||||
Certification | CE/ROHS | ||||||
Norminal Voltage | DC5V( 4.0 - 5.5 VDC) ;DC12V( 6 - 13.8 VDC) ;DC24V (12 - 27.6VDC);DC48V(24 - 56VDC) ; | ||||||
Applications | Hotels, Garment Shops, Building Material Shops, Manufacturing Plant, Machinery Repair Shops, Food & Beverage Factory, Farms,Restaurant, Home Use, Retail, Food Shop, Printing Shops, Construction works , Advertising Company, Other | ||||||
Speed Control : PWM VSP Temperature control fix speed with pressure intermittent ;
Out Signal : FG RD LD
Insulation Resistance : 10 MΩ/500V DC ;
Dielectric Strength : 2Min/500V AC /5mA
Out Signal : FG RD LD
Insulation Resistance : 10 MΩ/500V DC ;
Dielectric Strength : 2Min/500V AC /5mA
Factory Profile
ZHOUKOU BAOCHENG is a modernized factory specializing in fan production. We are committed to designing, manufacturing, and selling high-quality and high-performance fan products to provide customers with comfortable and healthy indoor air environments. Since our establishment, we have maintained a good reputation and customer trust. We have two advanced production lines and four efficient injection molding machines, allowing us to meet the large-scale production demands of various fan products. Whether it is DC cooling fans, AC cooling fans, or blowers, we can efficiently and effectively complete production with high quality.
Cooling Fan Manufacturing Process
More Model
DC Blower Fan
Fan Series (30x30x10 ~ 136x136x40)
Fan Series (30x30x10 ~ 136x136x40)
Size (MM) | Air Flow ( CFM) | Size (MM) | Air Flow ( CFM) |
20X20X6 | 0.15~0.37 | 50X50X15 | 2.22~4.75 |
30X30X10 | 0.85~1.48 | 60X60X28 | 3.98~6.64 |
40X40X10 | 1.17~2.01 | 75X75X30 | 6.94~20.83 |
40X40X20 | 2.45~3.27 | 97X97X33 | 15.8~22.40 |
45X45X10 | 2.83~3.6 | 120X120X32 | 18.45~27.68 |
Multiple plug types available
Applications
Wide range of applications, can be used in a variety of industry equipment：
3D printers, Stage lighting, VR equipment, Intelligent Manicure machine,Projector, High-speed camera, Head mounted display Automotive industry, Cabinet industry, Power industry, UAV application, Electric forklift, LED lighting industry, Hand held air detector, Charging machine,Nebulizer. Electromagnetic oven, Humidifier, Smart toilet, Intelligent household lampblack machine,Air purifier, Car GPS, Car LED lamp, Aromatherapy machine.CPU cooler, Case.
Computer power supplies Welding equipment UPS power systems CNC machines
Servers Computers Amplifier equipment Medical equipment
Certifications
Package & Delivery
Order Manufacturing
Knife Card Packaging
Suitable Carton Packaging
Cartons are neatly arranged
Winding film winding
Shipments on wooden pallets
FAQ
Q. Are you a factory?
A.Yes, we are the professional cooling fan factory.
We can provide cooling fans for you directly.
A.Yes, we are the professional cooling fan factory.
We can provide cooling fans for you directly.
Q. Can I customize cooling fan parameters?
A.Yes, we can customize cooling fans, size, voltage, current, speed, airflow, PWM, waterproof and etc.
You can tell us anything you want to achieve on the cooling fan.
Q. Can we get free samples?
A, we can provide free samples at each model.
Q. What I can do if I don't reach the MOQ 200pcs?
A.We can accept small order below 200pcs, just contact us, the price will have no big difference from 200pcs.
Q.What's your delivery date?
A.Sample lead time:2-7 working days；
Spot delivery time:2-14working days；
The delivery time of customized products depends on the specific quantity and customization difficulty.
Q: Can my order ship via UPS or DHL or FedEx or by Air or By Sea? And where is my order ship ?
A.Yes, we can ship.All orders ship from our factory warehouse.
A.Yes, we can customize cooling fans, size, voltage, current, speed, airflow, PWM, waterproof and etc.
You can tell us anything you want to achieve on the cooling fan.
Q. Can we get free samples?
A, we can provide free samples at each model.
Q. What I can do if I don't reach the MOQ 200pcs?
A.We can accept small order below 200pcs, just contact us, the price will have no big difference from 200pcs.
Q.What's your delivery date?
A.Sample lead time:2-7 working days；
Spot delivery time:2-14working days；
The delivery time of customized products depends on the specific quantity and customization difficulty.
Q: Can my order ship via UPS or DHL or FedEx or by Air or By Sea? And where is my order ship ?
A.Yes, we can ship.All orders ship from our factory warehouse.
