Price:$0.61 - $1.16

Quantity:


Product Overview

Description



Product Description











































Product Name Waterproof Connector
Contact Cores 2P/3P/4P/5P/6P/8P/9P/10P/12P/14P/16P/18P/20P/22P/24P/26P/28P
Connection Mode Wire to Wire / Wire to Panel
IP Level IP68
Shell Material PA66
Insert MaterialPPS
Insulation Resistance2000
Temperature Range-25℃~+85℃
Termination Solder




Product Overviews






















































































SD13 Connector
Contact Cores2P3P4P5P6P7P
Diameterφ2.8*1mmφ1.8*2mmφ1*3mmφ1*5mmφ1*6mmφ1*7mm
Rated Current5A5A5A5A5A5A
Operating Voltage380V AC250V AC250V AC250V AC250V AC250V AC
Pressure Resistance1500V1500V1500V1500V1500V1500V
Contact Resistance2mΩ2mΩ2mΩ2mΩ2mΩ2mΩ
Insulation Resistance2000MΩ2000MΩ2000MΩ2000MΩ2000MΩ2000MΩ
Cable Specifications≤4mm214AWG≤1.5mm218AWG≤0.75mm218AWG≤1.5mm218AWG≤1.5mm218AWG≤1.5mm218AWG

























































































SD16 Connector
Contact Cores2P3P4P5P6P7P9P
Diameterφ1.8*2mmφ1.8*3mmφ1*4mmφ1*5mmφ1*6mmφ1*7mmφ1*9mm
Rated Current10A10A5A5A5A5A5A
Operating Voltage380V380V250V250V250V250V250V
Pressure Resistance1500V1500V1500V1500V1500V1500V1500V
Contact Resistance2mΩ2mΩ5mΩ5mΩ5mΩ5mΩ5mΩ
Insulation Resistance2000MΩ2000MΩ2000MΩ2000MΩ2000MΩ2000MΩ2000MΩ
Cable Specifications≤1.5mm2/14WG≤1.5mm2/14WG≤0.75mm2/18WG≤0.75mm2/18WG≤0.75mm2/18WG≤0.75mm2/18WG≤0.75mm2/18WG























































































SD20 Connector
Contact Cores2P3P4P5P6P7P9P10P12P14P
Diameter/mmφ2.8*2φ2.8*3φ2.8*4φ2.8*5φ1.8*6φ1.8*7φ1.8*9φ1.8*10φ1.8*12φ1.8*14
Rated Current25A25A25A25A10A10A5A5A5A5A
Contact Resistance1mΩ1mΩ1mΩ1mΩ2mΩ2mΩ5mΩ5mΩ5mΩ5mΩ
Insulation Resistance2000MΩ2000MΩ2000MΩ2000MΩ2000MΩ2000MΩ2000MΩ2000MΩ2000MΩ2000MΩ
Cable Specifications/mm2/AWG≤4/12≤4/12≤4/12≤4/12≤1.5/14≤1.5/14≤0.75/18≤0.75/18≤0.75/18≤0.75/18

SD28.png-2
