The most cost effective renewable energy products solar panel 100kw system solar panel 12 volt 1 mw
The most cost-effective renewable energy products solar panel 100kw system solar panel 12 volt 1 mw
The most cost-effective renewable energy products solar panel 100kw system solar panel 12 volt 1 mw
The most cost-effective renewable energy products solar panel 100kw system solar panel 12 volt 1 mw
The most cost-effective renewable energy products solar panel 100kw system solar panel 12 volt 1 mw
The most cost-effective renewable energy products solar panel 100kw system solar panel 12 volt 1 mw
The most cost-effective renewable energy products solar panel 100kw system solar panel 12 volt 1 mw

The most cost effective renewable energy products solar panel 100kw system solar panel 12 volt 1 mw

Share on (1600955601037):


Price:$0.13 - $0.18

Quantity:


Product Overview

Description










LDK Solar PV Panels Layering

Every layer of material we adopt the first-class one to guarantee the quality and service life of the products. In addition, after
decades of manufacturing and serving experience, we have succeed to undergo the market test, and we have the moderate meanwhile
competitive price for our foreign customers.






Here are just our three most popular specifications M6,M10 and M12 Series,colour is dark blue, power is only from 430w to 550w,
monocrystal.
If you need any other color, power or polycrystalline solar panel, just contact us , we accept OEM and customization mass
production.


Model
M6 Series
Junction Box
IP68
Cell Type
Mono 182*91mm
Cable, Length
4mm2/350mm
Number of Cells
144 pcs (2x(6x12))
Weight
27.5KG
Type
Half Cut
Dimensions(L*W*H)
2094x1038x35mm
Type
9BB
Grade
Class A
Color
Dark Blue
Packing
31pcs per pallet
Frame
Anodized Aluminum
40'HQ
682PCS




Max. Power Output Pmax (W)
430w
435w
440w
445w
450w
Power Tolerance(%)
0~+3
0~+3
0~+3
0~+3
0~+3
Max. Power Voltage Vmp (V)
41.27
41.47
41.67
41.87
42.06
Max. Power Current Imp (A)
10.42
10.49
10.56
10.63
10.70
Open Circuit Voltage Voc (V)
49.65
49.85
50.05
50.26
50.43
Short Circuit Current lsc (A)
11.08
11.15
11.22
11.29
11.36
Module Effiffifficiency (%)
19.78
20.01
20.24
20.47
20.70







Model
M10 Series
Junction Box
IP68
Cell Type
Mono 182x91mm
Cable, Length
4mm2/350mm
Number of Cells
144 pcs (2x(6x12))
Weight
27.5kg
Type
Half Cut
Dimensions(L*W*H)
2279x1134x35mm
Type
10BB
Grade
Class A
Color
Dark Blue
Packing
31pcs per pallet
Frame
Anodized Aluminum
40'HQ
620PCS




Max. Power Output Pmax (W)
530w
535w
540w
545w
550w
Power Tolerance(%)
0~+3
0~+3
0~+3
0~+3
0~+3
Max. Power Voltage Vmp (V)
40.74
40.88
41.01
41.15
41.28
Max. Power Current Imp (A)
13.01
13.09


13.17
13.25
13.33
Open Circuit Voltage Voc (V)
49.26
49.40
49.53
49.67
49.80
Short Circuit Current lsc (A)
13.69
13.77
13.85
13.93
14.01
Module Efficiency (%)
20.51
20.70
20.89
21.09
21.28







Model
M12 Series
Junction Box
IP68
Cell Type
Mono 210x105mm
Cable, Length
4mm2/350mm
Number of Cells
108 pcs (2x(6x9))
Type
Half Cut
Dimensions(L*W*H)
1962x1303x35mm
Type
12BB
Packing
31pcs per pallet
Grade
Class A
40'HQ
744PCS
Weight
27.5kg
Frame
Anodized Aluminum




Max. Power Output Pmax (W)
525w
530w
535w
540w
545w
Power Tolerance(%)
0~+3
0~+3
0~+3
0~+3
0~+3
Max. Power Voltage Vmp (V)
30.61
30.81
31.01
31.21
31.41
Max. Power Current Imp (A)
17.15
17.20
17.25
17.30
17.35
Open Circuit Voltage Voc (V)
36.79
37.01
37.23
37.44
37.65
Short Circuit Current lsc (A)
18.16
18.21
18.26
18.32
18.37
Module Effiffifficiency (%)
20.54
20.73
21.12
21.32
21.71







Our back sheet is normally white, if you want the black type, it needs to be customized , please contact our sales.






Dear buyers, we supply not only mono crystal solar panel, but also polycrystal solar panel, mono type's power range from 430w to 670w, but the poly type's power range from 420w to 450w, welcome consult us.








LDK Brand Introduction
Xinyu LDK Power Supply Technology Co., Ltd founded in 2005, whose holding company now is Jiangxi Haiyuan Composites Technology Co Ltd. (stock code:002529, listed in NYSE). Now its current market value reaches 4.9 billion Yuan, equals 700 million US dollars.




If you want to know more about our brand’s story and history you could click and browse the website of our domestic website (it's Chinese, if you are using Google Chrome, you can automatically translated into your mother tongue):
(Baike of Baidu) https://baike.baidu.com/item/%E8%B5%9B%E7%BB%B4%E9%9B%86%E5%9B%A2/8445305?fr=aladdin




Our Certificates
We have already acquired a complete set of certificate such like ISO TUV CQC DEKRA CE.


Our Partner
We supply and manufacture about 1000Mw annually in collaboration with many partners at home and abroad.
Our domestic partners: JA solar, Trina solar etc. Our international partners: EPC, Enfinity, ESPE, EA Solar, SPI etc.




Market Distribution
Sell to Europe(28.00%),Africa(7.00%), Mid East(6.00%),Domestic Market(23.00%),Oceania(8.00%), Asia(21.00%),North America(4.00%),
South America(2.00%), Other(1.00%)








1. who are we?
We are based in Jiangsu, China, start from 2019, sell to Europe(28.00%),Africa(7.00%), Mid East(6.00%),Domestic Market(23.00%),Oceania(8.00%), Asia(21.00%),North America(4.00%), South America(2.00%), Other(1.00%) There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Solar Panel, Solar Cell, Storage Battery, Solar Inverter, Solar System, Solar controller, Solar Cable

4. why should you buy from us not from other suppliers?
dedicated to solar panel and solar related product for 18 years.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese
