MYAMI MY K12020PE 120V 20A 2400W High Voltage 3U Programmable DC Power Supply 120V Lab power supply for LED motor test aging
- Category: >>>
- Supplier: Guangzhou Myami Electronic Technology Co. Ltd.
Share on (1600958112920):
Product Overview
Description
MYAMI MY-K12020PE 120V 20A 2400W High Voltage 3U Programmable DC Power Supply 120V Lab power supply for LED motor test aging
0-120V/0-20A variable/2400W
4LED digital
4LED digital
Application:
(1) Aerospace Testing
(1) Aerospace Testing
(2) Photovoltaic and energy storage system
(3) New energy vehicle
(4) Data center
(5) Industrial motor
(6) Power semiconductor module
(7) Automated test system (ATE)
(8) Lithium fuel cell
(9) Aging of electronic equipment
(10) Precision electroplating, splashing and surface treatment
(3) New energy vehicle
(4) Data center
(5) Industrial motor
(6) Power semiconductor module
(7) Automated test system (ATE)
(8) Lithium fuel cell
(9) Aging of electronic equipment
(10) Precision electroplating, splashing and surface treatment
Feature:
(1) RS485 serial port is standard;
(2) SENSE serial port is standard;
(3) MUDBUS communication protocol;
(2) SENSE serial port is standard;
(3) MUDBUS communication protocol;
(4) The set value and the actual value are displayed in the same frame and can be compared；
(5) The maximum timing is 11 days；
(6) Single timing up to 12 hours；
Specification
Rated DC output (0℃~ 40℃) | ||
Voltage | 0-120V | |
Current | 0-20A | |
Voltage stability | ≤±(0.2%+0.05V) | |
Current stability | ≤±(0.5%+0.05A) | |
Load stability | ≤0.5% | |
Ripple & noise | ≤1% | |
Display resolution | ||
Voltage resolution | 10mV | |
Current resolution | 10mA | |
Power resolution | 1mW | |
Load resistance | 1mR | |
Operating environment | ||
Elevation | ≤2000m | |
Relative humidity | ＜80% | |
Environment temperature | 5℃~ 40℃ | |
Storage environment | ||
Environment temperature | -20~ 80℃ | |
Relative humidity | ≤80% | |
Power input | ||
Input | AC220V±10%,50Hz | |
Size | ||
Fuselage size | 410(D)×250(W)×155(H)mm | |
Package size | 520(D)×330(W)×250(H)mm | |
Weight | 8.5Kg | |
Model | Voltage | Current | Display | Accuracy |
MY-K1560PE | 0-15V | 0-60A | 4 LED | ≤±(0.2%+0.05V) |
MY-K15100PE | 0-15V | 0-100A | 4 LED | ≤±(0.2%+0.05V) |
MY-K2050PE | 0-20V | 0-50A | 4 LED | ≤±(0.2%+0.05V) |
MY-K3020PE | 0-30V | 0-20A | 4 LED | ≤±(0.2%+0.05V) |
MY-K3030PE | 0-30V | 0-30A | 4 LED | ≤±(0.2%+0.05V) |
MY-K3050PE | 0-30V | 0-50A | 4 LED | ≤±(0.2%+0.05V) |
MY-K3060PE | 0-30V | 0-60A | 4 LED | ≤±(0.2%+0.05V) |
MY-K3080PE | 0-30V | 0-80A | 4 LED | ≤±(0.2%+0.05V) |
MY-K30100PE | 0-30V | 0-100A | 4 LED | ≤±(0.2%+0.05V) |
MY-K30150PE | 0-30V | 0-150A | 4 LED | ≤±(0.2%+0.05V) |
MY-K30200PE | 0-30V | 0-200A | 4 LED | ≤±(0.2%+0.05V) |
MY-K5020PE | 0-50V | 0-20A | 4 LED | ≤±(0.2%+0.05V) |
MY-K5030PE | 0-50V | 0-30A | 4 LED | ≤±(0.2%+0.05V) |
MY-K5050PE | 0-50V | 0-50A | 4 LED | ≤±(0.2%+0.05V) |
MY-K5060PE | 0-50V | 0-60A | 4 LED | ≤±(0.2%+0.05V) |
MY-K6010PE | 0-60V | 0-10A | 4 LED | ≤±(0.2%+0.05V) |
MY-K6015PE | 0-60V | 0-15A | 4 LED | ≤±(0.2%+0.05V) |
MY-K6020PE | 0-60V | 0-20A | 4 LED | ≤±(0.2%+0.05V) |
MY-K6030PE | 0-60V | 0-30A | 4 LED | ≤±(0.2%+0.05V) |
MY-K6050PE | 0-60V | 0-50A | 4 LED | ≤±(0.2%+0.05V) |
MY-K6060PE | 0-60V | 0-60A | 4 LED | ≤±(0.2%+0.05V) |
MY-K8030PE | 0-80V | 0-30A | 4 LED | ≤±(0.2%+0.05V) |
MY-K10005PE | 0-100V | 0-5A | 4 LED | ≤±(0.2%+0.05V) |
MY-K10010PE | 0-100V | 0-10A | 4 LED | ≤±(0.2%+0.05V) |
MY-K10020PE | 0-100V | 0-20A | 4 LED | ≤±(0.2%+0.05V) |
MY-K10030PE | 0-100V | 0-30A | 4 LED | ≤±(0.2%+0.05V) |
MY-K12010PE | 0-120V | 0-10A | 4 LED | ≤±(0.2%+0.05V) |
MY-K12020PE | 0-120V | 0-20A | 4 LED | ≤±(0.2%+0.05V) |
MY-K12030PE | 0-120V | 0-30A | 4 LED | ≤±(0.2%+0.05V) |
MY-K15005PE | 0-150V | 0-5A | 4 LED | ≤±(0.2%+0.05V) |
MY-K15010PE | 0-150V | 0-10A | 4 LED | ≤±(0.2%+0.05V) |
MY-K20002PE | 0-200V | 0-2A | 4 LED | ≤±(0.2%+0.05V) |
MY-K20003PE | 0-200V | 0-3A | 4 LED | ≤±(0.2%+0.05V) |
MY-K20005PE | 0-200V | 0-5A | 4 LED | ≤±(0.2%+0.05V) |
MY-K22010PE | 0-220V | 0-10A | 4 LED | ≤±(0.2%+0.05V) |
MY-K30002PE | 0-300V | 0-2A | 4 LED | ≤±(0.2%+0.05V) |
MY-K30003PE | 0-300V | 0-3A | 4 LED | ≤±(0.2%+0.05V) |
MY-K30005PE | 0-300V | 0-5A | 4 LED | ≤±(0.2%+0.05V) |
MY-K40002PE | 0-400V | 0-2A | 4 LED | ≤±(0.2%+0.05V) |
MY-K40003PE | 0-400V | 0-3A | 4 LED | ≤±(0.2%+0.05V) |
MY-K40005PE | 0-400V | 0-5A | 4 LED | ≤±(0.2%+0.05V) |
MY-K50002PE | 0-500V | 0-2A | 4 LED | ≤±(0.2%+0.05V) |
MY-K50003PE | 0-500V | 0-3A | 4 LED | ≤±(0.2%+0.05V) |
MY-K50005PE | 0-500V | 0-5A | 4 LED | ≤±(0.2%+0.05V) |
MY-K60002PE | 0-600V | 0-2A | 4 LED | ≤±(0.2%+0.05V) |
MY-K60003PE | 0-600V | 0-3A | 4 LED | ≤±(0.2%+0.05V) |
Product Details
Recommend Products
Product Classification
Company Profile
Our Certificate
Exhibition
Packaging&Transportation
FAQ
Q1: What's the MOQ?
Re: The MOQ of machinery is 1 set.
Q2: What's delivery time?
Re: The general delivery time is 3~5 days after order confirmed, it depends on the order quantity.
Q3: Can you send the video to show how the machine works?
Re: Certainly, we have video of every machine, please feel free to contact us, we will send you machine video.
Q4: What's your payment terms?
Re:100% before shipment.
Q5: What's the payment method?
Re: We accept T/T and L/C payment.
