wholesales 100W 720P camera

Product Overview

Description

Main control (CPU)	Allwinner QG2101B+MTK7682 (WIFI module)
Memory	64MB flash
sensor	720p GC1054 CMOS sensor
lens	140° wide angle lens
Sensor performance	Support automatic white balance, automatic gain control, automatic backlight compensation
signal-to-noise ratio	≥39dB
Minimum illumination	0.8Lux/F1.4 (color mode), 0.3Lux/F1.4 (black and white mode)
night vision	Dual filters automatically switch, 6 850nmΦ28Mil high-power infrared lamps
night vision distance	3 meters works best, the longest distance is 20 meters
Motion Detection	PIR motion detection, sensitivity can adjust the detection distance (trigger immediately within the effective distance) Optimum 2 meters, maximum 4 meters (affected by ambient temperature and light)
video format	MP4 (H.264)
Video size/frame rate	720P/20fps
Recording method	1. Motion detection recording; 2. Button trigger recording; 3. Preview recording
Recording video duration	1. When motion detection is activated or a visitor presses the doorbell, the video will be recorded for 15 seconds and the doorbell will automatically enter sleep mode. After entering sleep mode, motion detection is activated or the doorbell is pressed, and another 15 seconds of video is recorded. 2. Each time the mobile APP enters the preview recording time, it is limited to 3 minutes. Stop recording after 3 minutes.
Battery type/capacity	18650 battery cell 2600mAH*2=5200mAH
Battery discharge time	Two 18650 batteries sleep for 2 months Recording 30 15-second videos every day can last for 30 days (determined based on battery capacity. In addition, environmental factors and temperature affect battery life)
Network protocol	TCP/IP/HTTP/TCP/UDP/DHCP/DNS/DDNS/NTP/RTP/P2P
WIFI connection	2.4GHz wifi, support (802.11 b/g/n)
Ding dong	Support RF 433MHZ Ding Dong
memory	Supports cloud storage function (hardware does not have TF card function) Free cloud storage. The service is valid for 30 days. After expiration, cloud storage requires payment.
Operating Voltage	3.7V 18650 lithium battery
Working current	Start working current 260mA (milliamps), sleep standby current 1.7mA (microamps)
USB charging voltage	DC 5V/1.5A
Storage temperature(℃)	(0℃~50℃)
Operating temperature (℃)	Working temperature: -10~70℃, working humidity <95%
Wake up method	1. Doorbell button wake-up, 2. PIR detection wake-up, 3. Mobile phone active wake-up
APP access doorbell rules	1 master account + 8 shared accounts = 9 users can connect to the doorbell Only 3 users can preview the screen at the same time, and only one user can talk to the doorbell at a time.
use	When guests come to visit, they can make video calls and short-term recordings. The host can know the visitor's information without opening the door.
Features	Wireless connection, ultra-low power consumption, remote active wake-up, can support multiple accounts to watch online at the same time
