M3.0 Steel clamping wire connector electric terminal block pluggable terminal blocks
- Category: >>>
- Supplier: Cixi Zhongheng Electronics Co. Ltd.
Share on (1600966517537):
Product Overview
Description
Product Description
Product Paramenter
Pitch：12.0MM | ||
Part | Material | Plated |
Frame: | PA66 UL94V-0 | － |
Screw: | M3.0 Steel | Ni |
Clamp: | Brass | Ni |
Electrical | ||
Voltage: | 450V | |
Current: | 41A | |
Wire size: | 12-22AWG | |
Poles: | 2-12P | |
Insulation Reslistance: | 5000MΩ/1000V | |
Withstand Voltage: | AC2000V/1Min | |
Mechanical | ||
Acceptable Temperation: | -33℃~+120℃ | |
Max Soldering: | +250℃,5Sec | |
Strip Length: | － | |
