Wind Power System Small Wind Turbine Alternative Energy Generator 3000w 48v horizontal wind turbine for home use
- Category: >>>
- Supplier: Wuxi Flyt New Energy Technology Co. Ltd.
Share on (1600967413131):
Product Overview
Description
Product Features
1.Casting aluminum alloy body, compact, little vibration
2.Excellent output,900w at 8m/s
3.Easy installation, tube or flange connection optional
4.Reinforced glass fiber blades,matched with optimized aerodynamic shape and structure,which enhance the wind energy utilization
and annual output.
5.Tail adopts mechanical yaw technique, making it survive storm and run safely
6.Patented permanent magnet ac generator with special stator,effectively reduce torque, well match the wind wheel and generator,
and ensure the performance of whole system.
7.Controller,inverter can be matched according to customers’ specific needs
1.Casting aluminum alloy body, compact, little vibration
2.Excellent output,900w at 8m/s
3.Easy installation, tube or flange connection optional
4.Reinforced glass fiber blades,matched with optimized aerodynamic shape and structure,which enhance the wind energy utilization
and annual output.
5.Tail adopts mechanical yaw technique, making it survive storm and run safely
6.Patented permanent magnet ac generator with special stator,effectively reduce torque, well match the wind wheel and generator,
and ensure the performance of whole system.
7.Controller,inverter can be matched according to customers’ specific needs
Package list:
1. one set wind turbine .
2.one set bolts and nuts.
3.one piece flange.
4. one piece charge controller.
2.one set bolts and nuts.
3.one piece flange.
4. one piece charge controller.
Model | FK-3000 | ||||||||
Rated power | 3000W | ||||||||
Wheel diameter | 2.8m | ||||||||
Certification | CE | ||||||||
Rated voltage | 48V/96V/110V | ||||||||
Start-up wind speed | 2.5m/s | ||||||||
Rated wind speed | 10m/s | ||||||||
Survival wind speed | 40m/s | ||||||||
Number of blades | 3 | ||||||||
Blades material | reinforced glass fiber | ||||||||
Generator type | Three phase permanent magnet AC synchronous generator | ||||||||
Magnet material | NdFeB | ||||||||
Generator case | Casting aluminum alloy | ||||||||
Control system | Electromagnet | ||||||||
Yaw mode | 3,5KW Folding tail /10-20 Electronic yaw | ||||||||
Working temperature | -40°C - 80°C | ||||||||
1. A3 steel housing, makes small size, light weight, beautiful appearance and low working vibration.
2. flange connection ensures good strength, easy installation and maintenance.
3. enhanced fiberglass turbine blades with optimized aerodynamic shape design and structural design could lead low wind speed
start, high wind energy utilization. The blade surface is coated by gel coat resin and painted to resist corrosion by air and
water.
4. the automatic-yaw tail rudder empowers this horizontal swing-tail wind turbine (the tail automatically swings in high wind and
automatically return in safe wind)a higher anti-typhoon capacity.
5. the generator adopts permanent magnet external rotor design, which has a much better heat dissipation performance than inner
rotor design. Coupled with a special-designed stator, the resistance torque has been effectively reduced.
6. 42NSH magnetic steel piece has stronger magnetism and higher temperature resistance.
7. F-class enameled wire could stand 150 degrees temperature, coil operation safety is ensured.
8. the body shell is dacromet coated and twice anti-corrosion painted, to ensure rust free after a long time operation.
2. flange connection ensures good strength, easy installation and maintenance.
3. enhanced fiberglass turbine blades with optimized aerodynamic shape design and structural design could lead low wind speed
start, high wind energy utilization. The blade surface is coated by gel coat resin and painted to resist corrosion by air and
water.
4. the automatic-yaw tail rudder empowers this horizontal swing-tail wind turbine (the tail automatically swings in high wind and
automatically return in safe wind)a higher anti-typhoon capacity.
5. the generator adopts permanent magnet external rotor design, which has a much better heat dissipation performance than inner
rotor design. Coupled with a special-designed stator, the resistance torque has been effectively reduced.
6. 42NSH magnetic steel piece has stronger magnetism and higher temperature resistance.
7. F-class enameled wire could stand 150 degrees temperature, coil operation safety is ensured.
8. the body shell is dacromet coated and twice anti-corrosion painted, to ensure rust free after a long time operation.
The shipping method and costs are not the best for all countries, please contact us to check the best shipping way to your address and we will try to give you the biggest discount.
1,Competitive Price
--We are the factory/manufacturer so we can control production costs and then sell at the lowest price.
2,Controllable quality
--All products will be produced in our factory so we can show you every detail of the production and let you check the quality of the order.
3. Multiple payment methods
-- We accept online Alipay, bank transfer,Paypal ,LC, Western union etc.
4,Various forms of cooperation
--We are not only offer you our products, if it is needed, we could be your partner and design product according to your requirement. Our factory is your factory!
5.perfect after-sales service
--As a manufacturer of wind turbine and generator products for over 4 years,we are very experiences to dealing all kinds of problems. So whatever happens,we will solve it at the first time.
