Product Overview
Description
Products Description
Keyway Broaching Tool
Keyway broaches are essential tools used in machining and shaping operations. They are specifically designed to create keyways,which are grooves or slots that allow keys or other mating parts to fit into a shaft, hub, or other mechanical component. These broaches are commonly used in industries such as automotive, aerospace, manufacturing, and construction.
Keyway broaches come in various shapes, sizes, and styles to fit different applications. The most common types include standard broaches, push type broaches, and pull type broaches. Each type has its own unique design and methodology for removing material and creating keyways.
Keyway broaches come in various shapes, sizes, and styles to fit different applications. The most common types include standard broaches, push type broaches, and pull type broaches. Each type has its own unique design and methodology for removing material and creating keyways.
BROACH SIZE | SIZE IN MM | TOLERANCE | BROACH TOTAL LENGHT | KEYWAY DEPTH | SHIMS | NO.OF CUTS | LENGHT OF CUT IN STEEL 50 (min and max) | MAX PRESSURE |
1/16”-A | 1,5875 mm | 0 | 127 mm | 0.70 mm | - | 1 | 6-30 mm | 176 kg |
3/32”-A | 2,3813 mm | 0.047244094 | 127 mm | 0.90 mm | - | 1 | 6-30 mm | 353 kg |
1/8”-A | 3,175 mm | 0.200787402 | 127 mm | 1.30 mm | 1 | 2 | 6-30 mm | 294 kg |
3/32”-B | 2,3813 mm | 0.047244094 | 172 mm | 0.90 mm | - | 1 | 8-42 mm | 421 kg |
1/8”-B | 3,175 mm | 0.200787402 | 172 mm | 1.30 mm | 1 | 2 | 8-42 mm | 326 kg |
5/32”-B | 3,9688 mm | 0.149606299 | 172 mm | 1.70 mm | 1 | 2 | 8-42 mm | 598 kg |
3/16”-B | 4,7625 mm | 0.0051/ +0.0254 | 172 mm | 2.00 mm | 1 | 2 | 8-42 mm | 843 kg |
3/16”-C | 4,7625 mm | 0.0051/ +0.0254 | 299 mm | 2.00 mm | 1 | 2 | 10-64 mm | 698 kg |
¼”-C | 6,35 mm | 0.0051/ +0.0254 | 299 mm | 2.80 mm | 1 | 2 | 10-64 mm | 1143 kg |
5/16”-C | 7,9375 mm | 0.0051/ +0.0254 | 299 mm | 3.50 mm | 1 | 2 | 10-64 mm | 1796 kg |
3/8”-C | 9,525 mm | 0.5 | 299 mm | 4.10 mm | 2 | 3 | 10-64 mm | 1968 kg |
5/16”-D | 7,9375 mm | 0.200787402 | 353 mm | 3.50 mm | 1 | 2 | 25-150 mm | 3628 kg |
3/8”-D | 9,525 mm | 0.5 | 353 mm | 4.10 mm | 2 | 3 | 25-150 mm | 3175 kg |
7/16”-D | 11,1125 mm | 0.5 | 353 mm | 4.70 mm | 2 | 3 | 25-150 mm | 4263 Kg |
½”-D | 12,7 mm | 0.598425197 | 353 mm | 5.40 mm | 3 | 4 | 25-150 mm | 4445 kg |
9/16”-D | 14,2875 mm | 0.598425197 | 353 mm | 6,10 mm | 4 | 5 | 25-150 mm | 4036 kg |
5/8”-E | 15,875 mm | 0.5 | 394 mm | 6.80 mm | 4 | 5 | 25-150 mm | 4354 kg |
¾”-E | 19,05 mm | 0.6 | 394 mm | 8.10 mm | 5 | 6 | 25-150 mm/p> | 5397 kg |
7/8”-F | 22,225 mm | 0.6 | 515 mm | 9.60 mm | 6 | 7 | 25-150 mm | 4445 kg |
1”-F | 25,400 mm | 0.6 | 515 mm | 10.90 mm | 7 | 8 | 25-150 mm | 5034 kg |
Using a keyway broach provides several advantages. It allows for precise and accurate keyway creation, ensuring a proper fit between mating parts. It also eliminates the need for secondary machining operations, saving time and reducing costs.
Additionally, keyway broaches are versatile and can be used on a wide range of materials, including metals, plastics, and composites. When working with keyway broaches, it is important to follow proper safety procedures, such as wearing protective eyewear and gloves. Regular maintenance and sharpening of the broaches are also essential to ensure optimal performance and longevity.
This cutting tool is suitable for bordering and groove processing
It is widely used for punching, machining of machine accessories, suitable for bordering and groove processing in the .
