Product Overview

Description

ARM processor with 1500MHz Quad-core CPU Hi3716MV431 Main chipset DVB-S2X + DVB-T2/C combo tuner built-in 8GB EMMC FLASH / 1GB DDR3 Memory 2 x Common Interface slot (CI+) l Intemal 2.5” HDD Sata3 bracket (HDD Optional) Supported officially by OpenATV,OpenPLI www.Zgemma.org for more



You can use a USB Hard Disk Drive (HDD) to record all your favourite channels, listen to your music and watch a slideshow of your photos. What’s more, you can record up to 2 channels (on the same transponder) whilst watching a file from your USB HDD. You can even watch the .avi and .mkv file formats.



Make your TV screen more realistic, you can now watch channels in glorious High-Definition (HD), Full HD 1080p with Dolby Digital Plus to give you a superior audio experience. It’s also 3D ready.

It’s even Eco-friendly with 0.5W standby power consumption.

HbbTV Enjoy interactive services on your own living room. Zgemma is the "HbbTV" supported set-top box. "HbbTV", Hybrid Broadcast Broadband TV, is a major new pan-European initiative aimed at harmonizing the broadcast and broadband delivery of entertainment to the end consumer through connected TVs and Set-Top Boxes. In other words, HbbTV enables you to experience web browsing while watching the Live channel interactively at the same time. Main applications include TV Guide, Catch-up service, web video, VOD, or portal service. Additionally, you can check the weather, sports, news and etc,.



Specification:

• LinuxOperatingSystem


• High-performanceCortexA7processor


• Hi3716MV431Mainchipset


• Morethan4.10xlinuxkernel


• DVB-S2X+DVB-T2/Ccombotunerbuilt-in


• 512MBNANDFlash/512MBDDR3Memory


• 1xUSB2.0


• 1xHDMI2.0


• MPEG-1


• MPEG-2SP@MLandMP@HL


• MPEG-4SP@Levels0–3,ASP@Levels0–5,GMC,andMPEG-4short


• VP6/VP8


• 1-channel1080p@60fpsdecoding


• 10/100MbitEthernetInterface


• AdvancedEPG(ElectronicProgramGuide)


• User-friendlylinuxMenusystem


• Fullautomaticservicescan


• 3-layerOSD


• VariousChannelEditingPrograms


• Easyandfastsoftware-upgradeviaUSB


• Lowdeep-standbypowerconsumptionunder1W


• ParentalControl


• PluginService


• ExcellentsoundqualityinDolbyDigital


• OSDintomanylanguagesandgraphics(Skins)


• Webinterface,WEBRemotecontrol


• DiSEqC1.0/1.1/1.2andUSALS


• Externalpowersupply12V2A



Official DHL/FEDEX Partners(fast and safty delivery)

Official Original Software Support





 Note: We supply these receivers strictly as FTA only. We will not provide them with any patches pre-loaded and we can not help with any support for this. We provide support for the actual ZGEMMA hardware and for FTA reception only.
