Rotating electric controlled automatic horizontal rotation type three axis welding positioner
- Category: >>>
- Supplier: Jinan Guansen Automation Equipment Co. Ltd.Jinan Ltd.
Share on (1600968264120):
Product Overview
Description
Product Paramenters
Type | Three Axis S Type Horizontal Gyration Positioner | ||||
Model | AUT-TWP-S-500 | AUT-TWP-S-800 | AUT-TWP-S-1200 | ||
Rated Payload | 500kg+500kg(The 2nd shaft axis radius≤R400mm) | 800kg+800kg(The 2nd shaft axis radiuss≤R750mm) | 1200kg+1200kg(The 2nd shaft axis radius≤R600mm) | ||
Standard gyration radius of S1 | R1950mm | R2100mm | R2100mm | ||
Standard rotation radius of S2/S3 | R650mm | R850mm | R700mm | ||
Maximum load eccentricity | ≤200mm | ≤300mm | ≤200mm | ||
The height of clamping | ≤550mm(Over 550mm ,the bob-weight will increase with the actual load) | ≤650mm(Over 650mm ,the bob-weight will increase with the actual load) | ≤500mm(Over 500mm ,the bob-weight will increase with the actual load) | ||
Maximum gyration angle of S1 | ±180° | ±180° | ±180° | ||
Maximum rotation angle of S2/S3 | ±360° | ±360° | ±360° | ||
Rated gyration speed of S1 | 50°/S | 50°/S | 50°/S | ||
Rated rotation speed of S2 /S3 | 50°/S | 50°/S | 50°/S | ||
Repeat positioning accuracy | ±0.08mm(At R=400mm) | ±0.12mm(At R=750mm) | ±0.10mm(At R=600mm) | ||
Clamping size(L*W) | 2500mm*1200mm | 2200mm*1500mm | 2200mm*1200mm | ||
Positioner dimension(L*W*H) | 3900mm*2300mm*1700mm | 4200mm*2600mm*1700mm | 4200mm*2500mm*1700mm | ||
Height of S2/S3 rotation center | 650mm | 800mm | 800mm | ||
Equipment net weight | About 1500kg | About 1800kg | About 2300kg | ||
