Industrial evaporative condenser cooling tower closed type water tower cooling
Industrial evaporative condenser cooling tower closed type water tower cooling
Industrial evaporative condenser cooling tower closed type water tower cooling
Industrial evaporative condenser cooling tower closed type water tower cooling
Industrial evaporative condenser cooling tower closed type water tower cooling
Industrial evaporative condenser cooling tower closed type water tower cooling
Industrial evaporative condenser cooling tower closed type water tower cooling

Industrial evaporative condenser cooling tower closed type water tower cooling

Share on (1600969014381):


Price:$29,100.00 - $29,600.00

Quantity:


Product Overview

Description



Why Choose Us




Gaohua is a professional design & manufacturer of Evaporative Condenser in China. Our main products are evaporative condenser, closed cooling tower, air cooled heat exchanger, "air cooling + evaporative cooling" composite closed cooling system, anti-white mist efficient cooling system, etc. The products are widely used in power, chemical, metallurgy, petrochemical, coal chemical, air condition, food refrigeration industries and so on. Our plant covers an area of 13,500m2 and with ISO certificates. Our products are popular in domestic and international markets.


Products Description


Product Description of Evaporative Condenser
NZL Evaporative Condenser


The NZL evaporative condenser is a energy-saving, water-saving, high-efficiency and eco-friendly cooling tower which uses evaporation and condensation as the main mode of heat exchange. The vapor to be condensed is circulated through a condensing coil, which is continually wet on the outside by a recirculating water system. Air is pulled over the coil, causing a small portion of the recirculating water to evaporate. The evaporation removes heat from the vapor in the coil, causing it to condense. It takes up a small area and is easy to operate and maintain.














Details Description


Details Description of Evaporative Condenser










Product Paramenters


Parameters of Evaporative Condenser



Model
Dimension W×L
Coil Specifications
Axial fan
Model
Fan power
 (KW)
Air volume
Pump model
Water flow
m3/h
Inlet/Outlet Size
NBT-27
1430×1180
1260×1000*6
6.3#
1.1
15000
80/125-0.75/4
25
DN150/DN150
NBT-36
1430×1180
1260×1000*8
6.3#
1.1
15000
80/125-0.75/4
25
DN150/DN150
NBT-45
1430×1180
1260×1000*10
6.3#
1.5
18500
80/125-0.75/4
25
DN150/DN150
NBT-48
2600×1430
1260×2430*4
6.3#
1.1*2
15000*2
80/160-1.1/4
35
DN150/DN150
NBT-72
2600×1430
1260×2430*6
6.3#
1.1*2
15000*2
80/160-1.1/4
35
DN150/DN150
NBT-93
2600×1430
1260×2430*8
9#
2.2*2
26000*2
80/160-1.1/4
35
DN150/DN150
NBT-120
2600×1430
1260×2430*10
9#
2.2*2
26000*2
125/125-2.2/4
60
DN150/DN150
NBT-145
2600×1430
1260×2430*12
9#
2.2*2
26000*2
125/125-2.2/4
60
DN150/DN150








NBT-96
2620×2720
1260×2430*4
13#
4
55000
125/125-2.2/4
60
DN150/DN150
NBT-145
2620×2720
1260×2430*6
15#
5.5
78000
125/125-2.2/4
60
DN150/DN150
NBT-193
2620×2720
1260×2430*8
15#
5.5
78000
125/125-2.2/4
60
DN150/DN150
NBT-241
2620×2720
1260×2430*10
16#
5.5
80000
125/150-3/4
78
DN150/DN150
NBT-290
2620×2720
1260×2430*12
16#
7.5
10000
125/160-4/4
78
DN150/DN150
NBT-181
3190×2720
1260×2430*6
16#
7.5
10000
125/160-4/4
120
DN150/DN150
NBT-241
3190×2720
1260×3000*8
16#
7.5
10000
125/160-4/4
120
DN150/DN150
NBT-302
3190×2720
1260×3000*10
18#
11
125000
125/160-4/4
120
DN150/DN150
NBT-362
3190×2720
1260×3000*12
18#
11
125000
125/160-4/4
120
DN150/DN150


Our Advantages


(1) Power-saving; Water-saving; Space-saving;
(2) High Heat Exchange Ability;
(3) Easy to install;
(4) Low maintenance cost;
(5) Long lifetime.


Main Parts




Packaging & Delivery




Project cases










You may like








FAQ
Q1. If I want to get a quotation quickly, what necessary parameters should I provide?
A: Flow rate, Inlet and Outlet temperature, Wet-bulb temperature.

Q2. Which industries can evaporative condensers be used in?
A: Evaporative condensers can be used in electric power, metallurgy, petrochemical, coal chemical, food refrigeration and other industries.

Q3. What material of heat exchange tube should I choose?
A: If the medium of the cooling tower is not corrosive, carbon steel hot-dip galvanizing is recommended, which is cheap; if the medium is corrosive, you can choose stainless steel with high corrosion resistance.

Q4. How long is the delivery time?
A: Usually, the delivery time is 45 days after receiving the advanced payment and drawing confirm.
