AB060 1stage Precision Planetary Gear Reducer for Food Machinery
- Category: >>>
- Supplier: Taizhou Hongze Trading Co. Ltd.
Share on (1600969279779):
Product Overview
Description
unit | stage | Reduction ratio | AB060 | AB090 | AB115 | AB142 | ||||
Maximum output torque T | Nm | 1/2 | 3-100 | 3 times rated output torque | ||||||
Rated output speed N | rpm | 1/2 | 3-100 | 5000 | 4000 | 4000 | 3000 | |||
Maximum output speed N | rpm | 1/2 | 3-100 | 10000 | 8000 | 8000 | 6000 | |||
Ultra-precision backlash P0 | arcmin | 1/2 | 43534/12-100 | --- | ≤1/≤3 | ≤1/≤3 | ≤1/≤3 | |||
Precision backlash P1 | arcmin | 1/2 | 3-10/12-100 | ≤3/≤5 | ≤3/≤5 | ≤3/≤5 | ≤3/≤5 | |||
Standard backlash | arcmin | 1/2 | 3-10/12-100 | ≤5/≤7 | ≤5/≤7 | ≤5/≤7 | ≤5/≤7 | |||
Torsional rigidity | Nm/arcmin | 1/2 | 3-100 | 7 | 14 | 25 | 50 | |||
Allowable radial force F2rb² | N | 1/2 | 3-100 | 1530 | 3250 | 6700 | 9400 | |||
Allowable axial force F2rb² | N | 1/2 | 3-100 | 630 | 1300 | 3000 | 4000 | |||
Allowable axial force F2rb² | N | 1/2 | 3-100 | 765 | 1625 | 3350 | 4700 | |||
Service life | hr | 1/2 | 3-100 | 20000* | ||||||
efficiency | % | 1/2 | 3-10/12-100 | ≥97%/≥94% | ||||||
weight | kg | 1/2 | 3-10/12-100 | 2/3 | 4/5 | 9/10 | 16/19 | |||
Operating temperature | ℃ | 1/2 | 12-100 | -10℃~+90℃ | ||||||
lubricating | 1/2 | 3-100 | Lubricating oil imported from Japan | |||||||
Protection level | 1/2 | 3-100 | IP65 | |||||||
Installation direction | 1/2 | 3-100 | Any direction | |||||||
Voice value | Db | 1/2 | 3-100 | ≤58 | ≤60 | ≤63 | ≤65 | |||
Q1. Are you just a trading company?
A. No! Hongze Trading Ltd. is an export company of HONZEGEAR GROUP, which has own factory. Hongze company located in Wenling city center, that can attract most talented persons, to develop and stronger our international market.
Plant ADD: Building7, No. 8, Jinshan South Road, Binhai Town, Wenling Taizhou City, Zhejiang Province 317503, China
Office ADD: West Of 5/ F, No. 1139, Wanchang Middle Road, Wenling Taizhou City, Zhejiang Province 317500, China
Q2. Are the products on your website in stock?
Office ADD: West Of 5/ F, No. 1139, Wanchang Middle Road, Wenling Taizhou City, Zhejiang Province 317500, China
Q2. Are the products on your website in stock?
A. No, we do not carry finished products on the shelf. Everything we make is made to order.
Q3. What is advantage of Hongze (HONZEGEAR)?
Q3. What is advantage of Hongze (HONZEGEAR)?
A.-Application engineering assistance -Design service available
-Short delivery time. Our own factory has a specialized technical team and a one-stop production equipment such as CNC turning, CNC machining, teeth hobbing, teeth shaping, teeth shaving, teeth grinding, surface grinding, surface treatment and heat treatment.
-Very low backlash
-High precision
-CNC precision-machined housings and gears
-Custom manufactured parts in small or large quantities
Q4. Can you customized manufacture our gearbox from orignal design?
A. Yes, HONZEGEAR with IATF16949 Certificated. We have experienced engineering team with 24 hours support. Fast Prototype from your ideas.
