  • Private use 76mm 175W 3950RPM PMDC brushed Motor for small machines
Private use 76mm 175W 3950RPM PMDC brushed Motor for small machines
Private use 76mm 175W 3950RPM PMDC brushed Motor for small machines
Private use 76mm 175W 3950RPM PMDC brushed Motor for small machines
Private use 76mm 175W 3950RPM PMDC brushed Motor for small machines
Private use 76mm 175W 3950RPM PMDC brushed Motor for small machines
Private use 76mm 175W 3950RPM PMDC brushed Motor for small machines
Private use 76mm 175W 3950RPM PMDC brushed Motor for small machines

Private use 76mm 175W 3950RPM PMDC brushed Motor for small machines

Share on (1600969285871):


Price:USD 18.00 - USD 20.00

Quantity:


Product Overview

Description



Brushed DC Motor
Brushed DC motors offer advantages like cost-effectiveness, reliability and suitability for extreme operating environments.
Modar Motor offers high-quality and dependable brushed DC motors that suit a variety of applications. One tremendous benefit they provide is their high ratio of torque-to-inertia. This makes many brushed DC motors well-suited to applications requiring high levels of torque at low speeds.


Products Description




Product Specifications


Model
Voltage
Speed
Torque
Current
Power
V
rpm
Nm
A
W
MM76001
12
3600
0.1
4.4
38
MM76002
13.5
3600
0.45
15
165
MM76003
13.5
3950
0.43
17
175


item
value
Warranty
1year
Place of Origin
China
Jiangsu
Brand Name
Modar Motor
Model Number
MM76001/76002/76003
Usage
Home Appliance
Type
Brush Dc Motor
Torque
0.1/0.45/0.43N.m
Voltage
12V/13.5V
Construction
Permanent Magnet
Commutation
Brush
Speed(RPM)
3600/3950RPM/min
Continuous Current(A)
4.4/15/17A
Efficiency
Ie 3


Product Paramenters




Recommend Products


60ZYT-01/02/03/04/05B24
60mm brushed dc motor
Voltage: 24V
power: 0-150W
speed: 0-5000rpm
rated torque: 0.25N.m-0.4N.m
length: 111mm-160mm
63ZYT-01/02/03/04/05/06A24
63mm brushed dc motor
Voltage: 24V
power: 0-150W
speed: 0-5000rpm
rated torque: 0.1N.m-0.4N.m
length: 95mm-170mm
80ZYT-01/02/03A24
80mm brushed dc motor
Voltage: 12V/24V
power: 0-1000W
speed: 0-5000rpm
rated torque: 0.25N.m-0.55N.m
length: 145mm


If you want to know our other products, please click on the URL: https://modarmotor.en.alibaba.com






Manufacturing Technique






Packing & Delivery




Company Profile


Modar Motor
For more than 10 years, Modar Motor has offered BLDC motors, brushed DC motors, AC motors etc. available from 1 to 3000W in 12V, 24V, 48V, 310V versions. We also provide stepper motors, Linear actuator, pump motor for medical equipments etc..






FAQ


1. Who are we?
We are based in Jiangsu, China, start from 2021, sell to Eastern Europe(20.00%), North America(15.00%), Southeast Asia(10.00%),South America(10.00%), South Asia(5.00%), Southern Europe(5.00%),Northern Europe(5.00%), Central America(5.00%),Western Europe(5.00%), Eastern Asia(5.00%), Mid East(5.00%), Oceania(5.00%), Africa(5.00%). There are total about 5-10 people in our office.

2. How can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment.

3.What can you buy from us?
DC MOTOR, BRUSHLESS MOTOR, PUMP MOTOR, STEPPER MOTOR, AC MOTOR

4. Why should you buy from us not from other suppliers?
Specialized in designing and making DC motors, brushless motors, pump motors, ac motors, gearbox motor and motors for medical machines, auto machines.

5. What services can we provide?
Accepted Delivery Terms: FOB, CFR, CIF, EXW, FAS, CIP, FCA, CPT, DDP, DDU, DAF, DES；
Accepted Payment Currency: USD, EUR, JPY, CAD, AUD, HKD, CNY;
Accepted Payment Type: T/T, L/C, D/P, D/A, MoneyGram, Credit Card, PayPal, Western Union, Cash, Escrow;
Language Spoken:English, Chinese, German
