Wifi Circuit Breaker Smart Home Tuya Electrical With APP Control China Manufacturer MCB Intelligent RCBO
- Category: >>>
- Supplier: Shenzhen Home Warning Security Technology Co. Ltd.
Share on (1600970545764):
Product Overview
Description
Product Paramenters
Specification for Wifi Smart Circuit Breaker | ||
Model | MCB-2P-W | |
Rated voltage | AC230V (1P/2P) AC 400V (3P/4P) | |
Rated frequency | 50Hz/60Hz | |
Installation Category | Ⅱ | |
Protection level | IP20 | |
Rated current of shell frame | 100A | |
Rated current | 100A/80A/63A/50A/40A/32A/25A/20A/16A | |
Instantaneous release form | C | |
Rated impulse withstand voltage | 4000V | |
Control level voltage | AC 220V | |
Executive standards | CQC1149 GB/T16917.1 GB/T16917.22 | |
Drop test | GB/T4857.18 | |
EMC test | GB/T18499-2008 | |
Rated short-circuit breaking capacity | 3kA | |
Operating temperature | -5℃~+40℃ | |
Electrical lifespan | GB10963.1≥10000 times | |
Mechanical life | GB10963.1≥6000 times | |
operation frequency | IEEE 802 11 b / 2.4GHz | |
Protocol | WIFI | |
