SCITEK 158l Mixed with CFC free Ultra Low Temperature Freezer for laboratory
- Category: >>>
- Supplier: Scitek Global Co. Ltd.
Share on (1600972432261):
Product Overview
Description
Recommend Products
Products Description
Model Features
* High-performance V.I.P.(Vacuum Insulation Panel) insulation panels are used to minimize cabinet heat gain and improve temperature stability.
* Efficient cooling system operates the mixed refrigeration system for rapid and stable cooling, while being energy-saving and easy to maintain.
* The inner door has a unique design that separates storage compartments and minimizes frost buildup inside the chamber.
* Upright door with limit door hinge prevents collision when door opens.
* Lockable universal caster wheels for easy moving.Removable inner door for user to defrost and clean.
Reliability
* Safety password protected control panel prevents unauthorized system modification.
* Audible buzzer and visible flashing temperature alarm system for High/low temperature,Sensor error, Thermostat failure alarm,power failure alarm,door switch, ambient temperature alarm, condenser failure alarm, filter check alarm, voltage abnormal alarm, low battery alarm
* Door lock for storage safety
Ergonomic Design
* Upright door with limit door hinge prevents collision when door opens.
* Controller password protected to avoid unauthorized system modification.
* Lockable universal caster wheels for easy moving.
* Removable inner door for user to defrost and clean.
* High-performance V.I.P.(Vacuum Insulation Panel) insulation panels are used to minimize cabinet heat gain and improve temperature stability.
* Efficient cooling system operates the mixed refrigeration system for rapid and stable cooling, while being energy-saving and easy to maintain.
* The inner door has a unique design that separates storage compartments and minimizes frost buildup inside the chamber.
* Upright door with limit door hinge prevents collision when door opens.
* Lockable universal caster wheels for easy moving.Removable inner door for user to defrost and clean.
Reliability
* Safety password protected control panel prevents unauthorized system modification.
* Audible buzzer and visible flashing temperature alarm system for High/low temperature,Sensor error, Thermostat failure alarm,power failure alarm,door switch, ambient temperature alarm, condenser failure alarm, filter check alarm, voltage abnormal alarm, low battery alarm
* Door lock for storage safety
Ergonomic Design
* Upright door with limit door hinge prevents collision when door opens.
* Controller password protected to avoid unauthorized system modification.
* Lockable universal caster wheels for easy moving.
* Removable inner door for user to defrost and clean.
Product Parameters
Model | UFZ-86V30 | UFZ-86V110E | UFZ-86V160E | UFZ-86V940 | ||
Capacity (L) | 28 | 108 | 158 | 938 | ||
Size (WxDxH) | Internal (mm) | 270x265x400 | 460x460x510 | 460x455x800 | 1000x700x1335 | |
External (mm) | 470x490x1120 | 700x730x1260 | 700x700x1580 | 1240x1000x2000 | ||
Temperature | Range (℃） | -40~-86℃, adjustable | -40~-86℃, adjustable | -40~-86℃ adjustable | -40~-86℃ adjustable | |
Sensor | PTC | PTC | PTC | PTC | ||
Controller | Microprocessor | Microprocessor | Microprocessor | Microprocessor | ||
Cooling System | Refrigerant | Mixed with CFC free | Mixed with CFC free | Mixed with CFC free | Mixed with CFC free | |
Defrost | Manual | Manual | Manual | Manual | ||
Compressor (Qty) | SECOP/1 | SECOP/1 | SECOP/1 | SECOP/2 | ||
Display | LED | LED | LED | LED | ||
Audible& Visible Alarm | High/Low temperature | Standard | Standard | Standard | Standard | |
Abnormal ring temperature | Optional(LCD) | Optional(LCD) | Optional(LCD) | Optional(LCD) | ||
Sensor failure | Standard | Standard | Standard | Standard | ||
Condenser dirty blockage | Optional(LCD) | Optional(LCD) | Optional(LCD) | Optional(LCD) | ||
Low battery | Optional(LCD) | Optional(LCD) | Optional(LCD) | Optional(LCD) | ||
Power failure | Optional(LCD) | Optional(LCD) | Optional(LCD) | Optional(LCD) | ||
Door ajar | Optional(LCD) | Optional(LCD) | Optional(LCD) | Optional(LCD) | ||
Material | External | Electro-galvanized steel with antimicrobial powder coating | Electro-galvanized steel with antimicrobial powder coating | Electro-galvanized steel with antimicrobial powder coating | Electro-galvanized steel with antimicrobial powder coating | |
Inner door | 304 stainless steel | 304 stainless steel | 304 stainless steel | 304 stainless steel | ||
Casters | Standard | Standard | Standard | Standard | ||
Temperature recorder | Optional | Optional | Optional | Optional | ||
Test hole (Qty) / Diameter (mm) | 1/18 | 1/18 | 1/18 | 1/18 | ||
Shelves / Drawers (Qty) | Shelves / 1 | Shelves / 2 | Shelves / 2 | Shelves / 3 | ||
Sound Emission (dB) | 60 | 60 | 60 | 60 | ||
Electricity | Voltage / Frequency | 220V，50/60Hz;110V,60Hz | 220V，50/60Hz;110V,60Hz | 220V，50/60Hz;110V,60Hz | 220V，50/60Hz;110V,60Hz | |
Consumption (W) | 400 | 480 | 500 | 1020 | ||
N.W. / G.W. (kg) | 66/91 | 107/137 | 123/153 | 320/350 | ||
Shipping Size (WxDxH) (mm) | 550x590x1270 | 780x830x1410 | 780x800x1730 | 1320x1100x2150 | ||
