Ck5125/Ck5126 Cnc Vertical Lathe Machine Swiss Type Cnc Lathe Machine With Fanuc System
- Category: >>>
- Supplier: Henan Baishun Machinery Equipment Co. Ltd.
Share on (1600975243548):
Product Overview
Description
Product Overview
Ck5125/Ck5126 Cnc Vertical Lathe Machine Swiss Type Cnc Lathe Machin
Ck5125/Ck5126 Cnc Vertical Lathe Machine Swiss Type Cnc Lathe Machin is suitable to process ferrous metal, nonferrous metals and partial non-metallic material, and could achieve the processing of turning of the end face, inside and outside cylindrical surface, inside and outside circular conical surface and drilling, expanding, reaming of hole. Main transmission is driven by the spindle AC servo motor, hydraulic gear change and two gears step less speed regulation. Worktable is manual 4-jaw single movement chuck.
PRODUCT SPECIFICATIONS
Note:Our factory support customization,it can be customized according to customer needs!
Interested please contact : Whatsapp +86 18003851898
Model | CK5123 | CK5126 |
Max. turning diameter of vertical tool rest (mm) | 2300 | 2600 |
Working table diameter (mm) | 2000 | 2200 |
Max. height of work-piece (mm) | 1250 | 1400 |
Max. weight of work-piece (kg) | 8000 | 8000 |
Range of worktable rotation speed (rpm) | 3.2-100 | 2.2-70 |
Feeding series | Stepless | Stepless |
Range of tool rest feed (mm/min) | 0.8-86 | 0.8-86 |
Cross beam travel (mm) | 890 | 1090 |
Horizontal travel of tool rest (mm) | 1150 | 1300 |
Vertical travel of tool rest (mm) | 800 | 800 |
Size of section of cutter bar (mm) | 30*40 | 30*40 |
Main motor power (kw) | 30 | 30 |
Overall size of machine | 3050*4500*3450 | 2886*2672*3980 |
Machine weight | 18 | 19 |
