hybrid 8ch van logistic vehicle driving warning system mobile dvr car gps 4g wifi adas dms bsd black box motion detect hdd mdvr
- Category: >>>
- Supplier: Shenzhen Citops Systems Co. Ltd.
Share on (1600976354191):
Product Overview
Description
NOTE:
Order only include 8ch HDD AI Mdvr host with 4g+gps function
(Open ADAS + DSM algorithm, not included cameras )
It needs to be used with camera and other accessories.
Products Description
hybrid 8ch van logistic vehicle driving warning system mobile dvr car gps 4g wifi adas dms bsd black box motion detect hdd mdvr adopts a self-pop-up structure design of hard disk, high-speed processor NT98323 and embedded operating system, and integrates IT cutting-edge field H.264/H.265 video compression/ decompression, 4G network, GPS/BD positioning and other technologies.
* The interface can operate reliably and stably in complex environments
* Video encoding H.265/H.264
* Support 4G WIFI and GPS functional modules,Optional
* Supports Max 2Tb SSD/HDD+512G SD card For Storage
* The interface can operate reliably and stably in complex environments
* Video encoding H.265/H.264
* Support 4G WIFI and GPS functional modules,Optional
* Supports Max 2Tb SSD/HDD+512G SD card For Storage
* Rich peripheral interfaces
* Support external UPS battery life
* High scalability
* High scalability
Product Paramenters
project | parameter specification | ||
Audio and Video Inputs | video input | AHD：4/8ch 1080/25fps IPC：Scalable 1-4/8ch | |
audio input | 4ch audio iuput | ||
Audio and Video outputs | video output | Default 1-way CVBS output (VGA output optional) | |
speech output | 1ch audio output | ||
Audio and video parameter coding | video coding | H.264 Main Profile/H.265 | |
· Resolution | 1080P/720P/D1 optional | ||
audio coding | Default G.726,G.711A optional | ||
storage space | HDD | 1 2.5-inch optional: SSD/HDD hard disk | |
SD | Support 1 SD card | ||
wireless network | 4G | Supports 1 SIM card, optional: all major communication modules in the world | |
WIFI | 2.4/5.8G optional | ||
locate mode | BD/GPS | Support for mixed positioning, speed detection, time synchronization | |
interface | USB | USB2.0 interface, support export data, external engineering treasure | |
serial port | Support 2 RS232, 1 RS485, can be connected with external sensor | ||
I/O | 4 level inputs, 2 analog inputs, 2 alarm outputs | ||
network interface | Support external IPC, support hybrid NVR function | ||
· Intercom | 1 special intercom handheld mark interface | ||
Physical Specifications | size | 176.9mm（L）*186.8mm（W）*54mm（H） | |
weight | NW：1.4kg GW：2kg（M51H-DGNE1-L as a standard） | ||
work environment | operating temperature | -20〜+70℃ | |
operating humidity | · 8%〜90%（No condensation） | ||
Other | operator schema | remote control、APP、WEB | |
· Gravity sensor | Built-in G-Sensor | ||
Configurable AI algorithms | Driving Assistance,Face recognition,People Counting | ||
Details Images
Other Solutions
The product supports 4G+GPS, it is recommended to contact the customer for more information before placing an order.
