MYXL low cost commercial plastic film agricultural greenhouse manufacturer for sale
- Category: >>>
- Supplier: Myxl Greenhouse Tech And Dev Co. Ltd.
Share on (1600978376554):
Product Overview
Description
Products Description
Width | 6m-12m,,customized |
Height | 3m-7m,,customized |
Length | 20m-100m,customized |
Frame | Hot-galvanized steel structure |
Cover | Plastic Film(PEP/PO),Single / double layer membrane |
Material thickness | Thickness is 2mm , or 1.5mm |
Arch | 40x1.5mm, 48X1.5mm |
Accessories | Lock channel , wiggle wire, etc. |
SnowLoad | 0.4KN/M2 |
Wind Load | 0.5KN/M2 |
Rainfall load | 140mm/h |
Multi-span greenhouse, cost-saving and convenient to use , The greenhouse space utilization rate is high, the ventilation capacity is strong, and it can also prevent heat loss and cold air intrusion.
The ventilation in the middle of each span of the greenhouse can be used for large area ventilation.
Effectively reduce the temperature and humidity in the greenhouse, especially suitable for flowers and crops that do not require high humidity
Feature of film greenhouse
1. Greenhouse structure is made of hot galvanized steel, the diameter of column is optional.2. Greenhouse covering material have poly film. insect net, shade net.etc.
3. Plastic is fasten to greenhouse structure by locking profile with wiggle wire .
4. Greenhouse spans can be connected by gutter.
5. It is used for large area 6. Manual or electric side ventilation is optional.
Details Images
Internal and external sunshade nets
Sunshade net can be selected, reduce the temperature of the greenhouse, so that the temperature is under control, so that plants can grow better.
More details of the sunshade net can be understood by clicking on the picture！
Cover Material
The plastic film is superior to ordinary plastic films in terms of light transmittance, insulation, tensile strength, and aging resistance.
Frame Material
Hot-dip galvanized steel,The greenhouse frame is made of hot-dip galvanized steel pipe, no welding points, not easy tom rust, extend service life.Excellent hot-dip galvanized steel structure and accessories, anti-corrosion
Hot-dip galvanized steel,The greenhouse frame is made of hot-dip galvanized steel pipe, no welding points, not easy tom rust, extend service life.Excellent hot-dip galvanized steel structure and accessories, anti-corrosion
Complentary System
Completed environment-controlled greenhouse is available based on the different regions and its climates, which includes shading,natural ventilation, cooling or heating, fertigation, Irrigation, cultivation, hydroponic and auto-control systems etc.
Shading system
shade net/shading net/sunshade net
color:black,white,green
1. Using high-density HDPE raw materials, anti-ultraviolet, anti-radiation, shading rate up to 95%.
2. The mesh surface is flat, no broken wires, no voids, and encrypted edges.
3. Sunshade and sun protection, wind and wind resistance, heat preservation and moisturizing.
3. Sunshade and sun protection, wind and wind resistance, heat preservation and moisturizing.
Bench and Grow Lights
1.Grow racks/Bench/Seedbed:fixed bench,rotary bench and ebb&flow bench system.High space effiency,convenient for planting and high productive for crops.
2.LED Grow lights:Full-spectrum light output.DLC/ ETL Listed.High efficiency (2.7umol s -1 per watt).High output for high intensity.Ambient temperatures from 0°C（32°F) to 35°C (95°F)
Cooling system
cooling pad and cooling fan
Achieve the purpose of the ventilation, cooling, humidification, romove dust, get rid of the stink, and adding lots of oxygen content.
Irrigation System
Sprinkler Irrigation Systems and Drip Irrigation Pipes/Drip Tapes
1.Drip,impulse sprinkler, micro sprinkler and fog spray irrigation system.
2.Water saving and smart.
2.Water saving and smart.
Company Profile
Packaging & Delivery
Step 1: Design greenhouse drawings and plans
Step 2: Pack the greenhouse covering materials in woven bags
Step 3: Provide an introduction to the greenhouse in English
Step 4: Check the waterproof index for suitable and practical packaging
Step 5: Communicate with logistics to check appropriate details
Step 6: Control the delivery of each line.
According to customer requirements.
Certifications
FAQ
1. The land area is large. Should we use single-span or multi-span ?
It is related to the plants and project budget. The multi-span shed is more expensive and saves space, while the single span one is simpler to install and more economical.
2. How to determine the size of the greenhouse?
If there is fan and water pad the cooling system, it is better not to exceed 60 m.
If there are shading and blackout systems, should pay attention to the reasonable allocation of bays.
As for the span width, generally 6 m to 12 m. It is highly necessary to consider the climatic conditions and the growth requirements of the plants.
If there are shading and blackout systems, should pay attention to the reasonable allocation of bays.
As for the span width, generally 6 m to 12 m. It is highly necessary to consider the climatic conditions and the growth requirements of the plants.
3. Should the customers choose a round arch greenhouse or a spired roof greenhouse?
The round arch one is better against wind. The spire one is better against snow. And the round arch is cheaper;
4. How to install the greenhouse?
We can send engineers to site for building large scale greenhouse project. As for single greenhouse, it is recommended to install according to our installation guidance, and we can make detailed instructions for our customers;
5. How many sets of 300 square meter greenhouses can be loaded in a container?
It depends on the steel frame sizes. Generally, one 20' container can fit in 10-15 sets of single span greenhouse. And 40' can fit in about 20-24 sets of that;
It depends on the steel frame sizes. Generally, one 20' container can fit in 10-15 sets of single span greenhouse. And 40' can fit in about 20-24 sets of that;
6. Thickness of zinc layer of hot dip galvanizing pipe and thickness of zinc layer of galvanized zinc
220-275g, 20μ/150g, 15 -18μ;
7. How do we guarantee quality?
First we always uses high quality raw material. Second, we always make a pre-production sample before mass production to ensure that the finished products meet the needs of customers all the time; Third, there is always a final inspection before shipment;
8. What greenhouse products do we supply?
Various types of greenhouses, such as glass greenhouse, polycarbonate greenhouse, and film greenhouse. Meanwhile, there is also hydroponic greenhouse, garden greenhouse, commercial greenhouse.
9. Why choose us?
We are greenhouse manufacturer, ex-factory price, good quality with moderate price. Overall solution for greenhouse engineering. With rich experience, professional design, good after-sales service, installation supervision.
