Underground Mining Use Pneumatic Mucking Loading Machine ZQ 26
- Category: >>>
- Supplier: Jining Enwei Intelligent Technology Co. Ltd.
Share on (1600982489166):
Product Overview
Description
Products Description
Pneumatic Muck Rocker Shovel Rocker Air Rock Loading Machine Underground Mining Tunnel Rocker for mine coal
Pneumatic Rock Loader Rocker Shovel performance characteristics: downhole direct unloading bucket type pneumatic rock loader. Its purpose is to put the rock down into the tub. To achieve the mechanization of loading work, thereby reducing the labor intensity of workers, improve productivity. This direct unloading rocker ZQ-26 aerodynamic rock loader is mainly used for the horizontal exploration of pneumatic equipment, roadway, or tunnel roadway can also be used for cavern excavation or mine loading work.
ZQ26 pneumatic rock loader is used to load the rock, ore when the explosive blows up the big rock or ore.
Loading materials:gold, non-ferrous metal, black metal, nonmetal, and rock, ore, and etc.
It can be used in a explosion proof fields. The max. diameter of the medium is 500mm.
When the diameter is 250mm, the loading efficiency is best. It runs on the railway track, so the wheel gauge is 600mm in normal, if the gauge is 762mm, 900mm, or others, pls tell in advance.
ZQ26 pneumatic rock loader is used to load the rock, ore when the explosive blows up the big rock or ore.
Loading materials:gold, non-ferrous metal, black metal, nonmetal, and rock, ore, and etc.
It can be used in a explosion proof fields. The max. diameter of the medium is 500mm.
When the diameter is 250mm, the loading efficiency is best. It runs on the railway track, so the wheel gauge is 600mm in normal, if the gauge is 762mm, 900mm, or others, pls tell in advance.
Product Parameters
Type | Z-17AW | Z-20 | Z-20AW | Z-30AW | ZQ-26 | ||||||
Loading Capacity (m3/h) | 20-30 | 30-40 | 30-40 | 50-60 | 40-50 | ||||||
Capacity(m3) | 0.17 | 0.2 | 0.2 | 0.3 | 0.26 | ||||||
Loading Width(M) | 1.7 | 2.0 | 2.0 | 2.2 | 2.7 | ||||||
Rail Gauge(mm) | 600mm (When the rail gauge is 750mm,762mm, pls mark in the order) | ||||||||||
Power | Electric motor | Electric motor | Electric motor | Electric motor | wind motor | ||||||
Travel Power(kw) | 10.5 | 10.5 | 10.5 | 1.5 | 10.5 | ||||||
Raising Hopper Power(kw) | 10.5 | 10.5 | 13 | 15 | 15 | ||||||
Discharge Height(mm) | 1250 | 1330 | 1360 | 1370 | 1250 | ||||||
Length (bucket down) L | 2120 | 2480 | 2400 | 2620 | 2375 | ||||||
Width (pedal down) | 1011 | 1210 | 1330 | 1300 | 1380 | ||||||
Height (bucket working) H2 | 1920 | 2180 | 2180 | 2260 | 2240 | ||||||
Height (bucket down) H1 | 1200 | 1518 | 1460 | 1545 | 1455 | ||||||
Weight(kg) | 3760 | 3750 | 3700 | 4600 | 2700 | ||||||
Details Images
Company Profile
Factory Show
Contact:
Mobile/Wechat:+86-18660767011
Whatsapp:+86-15066371715
