Factory Customized High Brightness Advertising Screen Pole LED Video Wall P5 P6 P8 P10 Full Color Outdoor Screen LED Display
- Category: >>>
- Supplier: Shenzhen Huaxintong Photoelectric Technology Co. Ltd.
Share on (1600982672040):
Product Overview
Description
Related Products
Product Description
Specifications
Item | Parameter | Parameter | Parameter |
Pixel Pitch | 6.67mm | 8mm | 10mm |
LED Lamp | SMD2525 | SMD2727 | SMD3535 |
Density | 22477dot/m2 | 15625dot/m2 | 10000dot/m2 |
Module Size | 320*160mm | 320*160mm | 320*160mm |
Module Pixels | 48*24=1152dot | 40*20=800dot | 32*16=512dot |
Caninet Size | 960mm*960mm | 960mm*960mm | 960mm*960mm |
Cabinet Weight | 6.5KG | 6.5KG | 6.5KG |
Brightness/Adjustment | ≥5000cd/m2 | ≥5000cd/m2 | ≥6000cd/m2 |
View Angle | ≥160°/≥160° | ≥160°/≥160° | ≥160°/≥160° |
Best View Distance | 4-100m | 5-100m | 6-100m |
Grey Scale | 65536 | 65536 | 65536 |
Refresh Rate | ≥1920Hz | ≥1920Hz | ≥1920Hz |
Scan Mode | 1/6 Scan | 1/5 Scan | 1/2 Scan |
Life span | >100,000(Hrs) | >100,000(Hrs) | >100,000(Hrs) |
MTBF | >5000(Hrs) | >5000(Hrs) | >5000(Hrs) |
Out of control pixel rate | ≥3/10,000(discrete distribution) | ≥3/10,000(discrete distribution) | ≥3/10,000(discrete distribution) |
Operation Temperature | -10℃~+50℃ | -10℃~+50℃ | -10℃~+50℃ |
Working Humidity | 10%~98%RH | 10%~98%RH | 10%~98%RH |
Storage Temperature | -40℃~+85℃ | -40℃~+85℃ | -40℃~+85℃ |
Working Valtage | AC 110~240 V ±10% | AC 110~240 V ±10% | AC 110~240 V ±10% |
IP Grade | IP67 | IP67 | IP67 |
Schematic of the control system
Packing and shipping
wooden box packaging
Delivery method
Application
P8 in Toronto
P6.67 in Toronto
P8 in Toronto
P5 in Japan
P10 in Xiamen
P10 in South Korea
Certifications
Our Factory
FAQ
