Meritsun Energy Storage Container 700V Air Cooling Lifepo4 Battery High Voltage Lithium Battery for Commercial energy storage
- Category: >>>
- Supplier: Guangzhou Meritech Power Co. Ltd.
Share on (1600985286559):
Product Overview
Description
Products Description
Products Specification
LiFePO4 Battery parameter | ||||
Module Voltage | 51.2V | |||
Rated capacity | 100Ah | |||
Pack | 1P-16S | |||
BMUinside | 1 | |||
Dimension（W*D*H） | 470*442*154 | |||
Coolingmode | Naturalcooling | |||
PowerTerminal | Plug-intype | |||
Battery Energy Storage System | ||||
Voltage Range(V) | 150~750 | 3~13 modules | ||
Series&Parallels | 1P48~208S | 【Max 3 clusters parallel】 | ||
Rated Voltage(V) | 614.4 | 【Max 3 clusters parallel】 | ||
Rated Capacity(Ah) | 100 | |||
Rated charge/discharge current(A) | 50/50 | 20～35℃，SOC:10～100% | ||
Rated Energy(kWh)s | 15.36~66.56 | 3~13 modules | ||
Maximum Discharge Current(A) | 100 | |||
Maximum ChargeCurrent(A) | 100 | |||
Discharge cut-off voltage(V) | 537.6 | |||
Charge voltage(V) | 672 | |||
Cycle life (@25c ，0.5C/0.5C, 80%DOD) | ＞8000 | |||
IP Grade | IP20 | |||
Battery Thermal Management | Natural cooling | |||
Operating temperature | -10- 45℃ | |||
Operating humidity | 5%~95%R.H. | |||
Communication | CAN/RS485 | |||
LCD Screen monitor | Touch screen, check battery data & setup parameters | |||
FAQ
FAQ
Q1:Who are we?A:We are based in Guangzhou Guangdong, China, starting from 1999, a manufacturer and solution provider of energy storage system
products, sold to America, Africa, Europe, Southeast Asia, and Middle East.
Q2:What products I can buy from you?
A:Storage lithium battery, portable storage system, residential energy storage system, container energy storage system, etc.
Q3:Can you supply OEM & ODM service?
A:Yes, we can do OEM & ODM as per your requirements.
Q4:What’s your MOQ?
A:Sample order is acceptable, but for customized products the MOQ is different based on different model.
Need more details please feel free to contact us online or by mail (partners@meritsunpower.com) at any time.
Q5:How do you guarantee your product's quality?
A:Our factory has many certifications, from incoming materials to production, and then to delivery, we have a complete quality
control management system to guarantee the quality of every step.
Q6: What kind of certificates do you have for your product?
A:Our products have the certificates of CE, UL, MSDS, IEC, UN38.3, etc.
Q7:Can I become your dealer and what's the requirement?
A:Yes, we are glad to work with you, but the requirements are different according to different area, for details information
welcome to contact us online or by mail (partners@meritsunpower.com) at any time.
