655nm convenient operation red laser diode module for measuring spectrum analyzer laser lighting show
- Category: >>>
- Supplier: Changchun New Industries Optoelectronics Tech Co. Ltd.
Share on (1600986563763):
Product Overview
Description
Product Description
Central wavelength (nm) | 650± 12 | 655± 10 | |||
Operating mode | CW | ||||
Output power (mW) | > 1, 100, 200, … , 1000 | ||||
Power stability (rms, over 4 hours) | <3%, <2%, < 1%, <0.5% | ||||
Transverse mode | Multimode | ||||
Beam diameter at the aperture (mm) | ~ 10×5 | ||||
Beam divergence, full angle (mrad) | <3.0 | ||||
Warm-up time (minutes) | <5 | ||||
Beam height from base plate (mm) | 24. 8 | ||||
Operating temperature (C) | 10~35 | ||||
Power supply | 85-264VAC | PSU-III-LED/ PSU-III-FDA (Frequency for 1Hz-30kHz) | |||
100-240VAC | PSU-A-D (Frequency for 30kHz - 100kHz) | ||||
TTL / Analog modulation | TTL or Analog with 1Hz- 1kHz 1kHz- 10kHz, 10kHz-30kHz, 30kHz- 100kHz optional | ||||
Expected lifetime (hours) | 10000 | ||||
Warranty | 1 year | ||||
