Max. Gate weight 1500kg AC motor small automatic gate openers for sliding gate Risesat RS SG01B
Max. Gate weight 1500kg AC motor small automatic gate openers for sliding gate Risesat RS-SG01B
Max. Gate weight 1500kg AC motor small automatic gate openers for sliding gate Risesat RS-SG01B
Max. Gate weight 1500kg AC motor small automatic gate openers for sliding gate Risesat RS-SG01B

Max. Gate weight 1500kg AC motor small automatic gate openers for sliding gate Risesat RS SG01B

Share on (1600987329181):


Price:$99.00 - $125.00

Quantity:


Product Overview

Description



Product Description




Product Paramenters


Features:
RS-SG01 is the new sliding gate opener.
The open door weighs up to 500kgs and is used in homes .

The motor will be automatically cut off when the temperature reaches the rate value.

Gear with end cover protection, more secure and reliable.

Turbo worm transmission mechanism, transmission stability.

Auto-shuttering back the door against touching, soft start and soft stop.

Convenient installation, when power failure can open the clutch, manual opening.




Item No.
RS-SG02A
RS-SG02B
Input voltage
220V AC / 50Hz
220V AC / 50Hz
Motor speed
1400r/min
1400r/min
Output torque
25N.m
32N. m
Motor power
370W
550W
Max. gate weight
1000kg
1500N
Speed
12m/min
12m/min
Limit switch
Spring/Magnetic       NO/NC
Spring/Magnetic NO/NC
Temperature
-45 ~ + 65 degree
-45 ~ + 65 degree
Noise
<=56dB
<=56dB
Gear Teeth
17T/19T
17T/19T
