hybrid inverter solar 4.2kw inverter 4.2kw solar power inverter dual output
hybrid inverter solar 4.2kw inverter 4.2kw solar power inverter dual output
hybrid inverter solar 4.2kw inverter 4.2kw solar power inverter dual output
hybrid inverter solar 4.2kw inverter 4.2kw solar power inverter dual output
hybrid inverter solar 4.2kw inverter 4.2kw solar power inverter dual output
hybrid inverter solar 4.2kw inverter 4.2kw solar power inverter dual output

hybrid inverter solar 4.2kw inverter 4.2kw solar power inverter dual output

Share on (1600991129756):


Price:$135.00 - $140.00

Quantity:


Product Overview

Description





Product Description




Model
HYG4. 2KW
HYGMAX-6.2 KW
HYGMAX-8.2KW
HYGMAX-10.2KW
RATED POWER
4200VA/4200W
6200VA/6200W
8200VA/8200W
10200VA/10200W
GRID-TIE OPERATION
PV INPUT (DC)
Normal DC/Max DC voltage
360VDC/500VDC
Start-up/Feeding Voltage
90VDC/120VDC
MPPT Voltage Range
90VDC~450VDC
Number of MPPT Trackers/lax input A
1/27A
Waveform
Pure sine wave
GRID OUTPUT(DC)
Normal Output Voltage
220/230/240 VDC
Output Voltage Range
195'253 VDC
Normal Output Current
18.2 A
18.2 A
35.6 A
44.3A
Power Factor
>0.99
Feed-in Grid Frequency Range
19-51士1Hz
MAX Conversion EFFICIENCY(DC/AC)
98%
THO LOAD OUTPUT POWER
Full Load
4200W
6200W
8200W
10200W
Maximum Main Load
4200W
6200W
8200W
10200W
Maximum Second Load (battery mode)
1400W
2067W
2733W
3400W
Main Load Cut Of Voltage
22VDC
44VDC
44VDC
44VDC
Main Load Return Voltage
24VDC
48VDC
54VDC
44VDC
OFF-GRID OPERATION
AC INPUT
AC Start-up Voltage/Auto Restart Voltage
120-140VAC/180VAC
Acceptable Input Voltage Range
90-280VAC or 170-280VAC
Maximum AC Input Current
30A
40A
40A
40A
Nominal operat ing frequency
50/60Hz
Surge Power
8400W
12400W
16400W
20400W
PV INPUT (C)
Maximum DC Voltage
500VDC
MPPT Voltage Range
90VDC'450VDC
BATTERY MODE OUTPUT(AC)
Nominal Output Voltage
220/230/240VAC
Output Waveform
Pure sine wave
Efficiency(DC to AC)
94%
BATTERY &CHARGER
Nominal DC Voltage
24VDC
48VDC
48VDC
48VDC
Max Solar charging Current
40A
40A
60A
60A
Max AC Charging Current
100A
100A
140A
140A
Dimension DXWXH(mm)
420*310*110
Net weight(kgs)
11
11
14.2
14.5
Communication Port
RS232/WIFI/Remove LCD/GPRS
Operating Temperature
-10~50C


Specification


item
value
Place of Origin
China
Guangdong
Brand Name
OUYAD
Model Number
HYG4. 2KW
Input Voltage
24VDC/ 230VAC
Output Voltage
230V AC
Output Frequency
50HZ/60HZ
Output Type
Dual
Size
420*310*110mm
Type
DC/AC Inverters
Inverter Efficiency
94%
Certificate
CE, ROHS
Warranty
1 YEAR
Weight
11KG
Name
4.2kw solar inverter
Capacity
4.2KW
Battery voltage
24V
Controller type
40A MPPT
MPPT RANGE
90-450VDC
Output waveform
Pure Sine Wave Solar Inverter
Color
Red,Green,Silver, blue
OEM
SUPPORT
Lead Time
15 days for sample; 15 days for bulk order.


Packing & Delivery




Carton box


Company Profile






Company info. & Advantages
OUYAD Group was established in 2000, main products are solar modules(power from 5Wp to 370Wp), wind turbine generator system(power from 200W to 50KW), inverters, UPS and batteries for wind/solar power systems.

Main Honor:
2010 Ouyad was accredited as "High-Tech Enterprise of Guangdong Province" by Guangdong Province government;
2014 Ouyad was accredited as "National High-Tech Enterprise" by China government;
2016 Ouyad was accredited as "Foshan City Smart Wind & Solar Hybrid Power System engineering technology research Center" by Foshan City government;
2017 Ouyad was accredited as "Guangdong Province Smart Wind & Solar Hybrid Power System engineering technology research Center" by Guangdong Province government;

Product Quality Control
Ouyad Group as an export-oriented company, product quality standards are in full accordance with international standards like IS09001, GB/T28001-2011,IDTOHSHS18001:2007. Products all international certified like CE, CQC, VDE, LVD, SONCAP, Inmetro etc.


FAQ


1. who are we?
We are based in Guangdong, China, start from 2007,sell to Africa(32.00%),Mid East(30.00%),Domestic Market(15.00%),Southeast Asia(15.00%),North America(2.00%),Western Europe(2.00%),Eastern Europe(2.00%),Northern Europe(2.00%). There are total about 51-100 people in our office.

2. how can we guarantee quality?
Always a pre-production sample before mass production;
Always final Inspection before shipment;

3.what can you buy from us?
Inverter,Solar,Panel,Windturbine,Lithium Ion Battery

4. why should you buy from us not from other suppliers?
Company info. & Advantages
OUYAD Group was established in 2000, Ouyad Group is a scientific and technological enterprise engaged in the research, development and production of solar, wind and ternary lithium battery energy storage systems,solar inverter.

5. what services can we provide?
Accepted Delivery Terms: FOB,CFR,CIF,EXW,FAS,CIP,FCA,CPT,DEQ,DDP,DDU,Express Delivery,DAF,DES；
Accepted Payment Currency:USD,EUR,JPY,CAD,AUD,HKD,GBP,CNY,CHF;
Accepted Payment Type: T/T,L/C,D/P D/A,MoneyGram,Credit Card,PayPal,Western Union,Cash,Escrow;
Language Spoken:English,Chinese
