Solar Air Conditioner and Solar Panel System 24v 200Ah Lifepo4 PowerWall Lifepo4 Battery
- Category: >>>
- Supplier: Ningbo Essolx Solar Co. Ltd
Share on (1600994435939):
Product Overview
Description
Product Description
Specification
Wall Mounted Power Wall 24V/200Ah Lithium Ion Battery | ||
Nominal Voltage(V) | 25.6 | |
Nominal capacity(AH) | 210 | |
Nominal energy capacity(kWh) | 5.3 | |
Operating voltage range | 22.4-29.2 | |
Recommended charging voltage(V) | 28 | |
Recommended discharge cut-off voltage(V) | 24 | |
Standard charging current(A) | 100 | |
Maximum continuous charging current(A) | 200 | |
Standard discharge current(A) | 100 | |
Maximum discharge current(A) | 200 | |
Applicable temperature(°C) | -30 ~ 60(Recommended 10 ~ 35) | |
Allowable humidity range(%rh) | 0~ 95% no condensation | |
Storage temperature(°C) | -20 ~ 65(Recommended 10 ~ 35) | |
Protection level | IP20 | |
cooling method | natural air cooling | |
Life cycles | 6000+ times at 80% DOD | |
Maximum size (DxWxH)mm | 596*545*155 | |
Weight (KGS) | 48 | |
FEATURES
1.Using the technology of LiFePO4 cell,superior safety,thousands of cycles,under normal conditions.
2.Built-in automatic protection of over-charge,over discharge,over current and over temperature.
3.Lighter Weight:About 40% of the weight or a comparable lead acid battery.
4.Higher Power:High Discharge rate and High Energy Capacity.
5.Wider Temperature Range:-20℃ to 60 ℃
1.Using the technology of LiFePO4 cell,superior safety,thousands of cycles,under normal conditions.
2.Built-in automatic protection of over-charge,over discharge,over current and over temperature.
3.Lighter Weight:About 40% of the weight or a comparable lead acid battery.
4.Higher Power:High Discharge rate and High Energy Capacity.
5.Wider Temperature Range:-20℃ to 60 ℃
Built in high class inteligent BMS
The batteries are equipped with a high class BMS (battery management system).The task of this system is to monitor the voltage and
temperature of the cells during both charging and discharging.If dangerous values are exceeded,the system cuts off the power
supply,thus ensuring the safety of the battery,connected devices and most of all,the user!
temperature of the cells during both charging and discharging.If dangerous values are exceeded,the system cuts off the power
supply,thus ensuring the safety of the battery,connected devices and most of all,the user!
1.What is the difference between a lithium-ion battery and a regular battery?
Lithium batteries feature primary cell construction. This means that they are single-use—or non-rechargeable. Ion batteries, on the other hand, feature secondary cell construction. This means that they can be recharged and used over and over again.
2. What is lithium-ion battery and how does it work?
The anode and cathode store the lithium. The electrolyte carries positively charged lithium ions from the anode to the cathode and vice versa through the separator. The movement of the lithium ions creates free electrons in the anode which creates a charge at the positive current collector.
3. What are lithium-ion batteries used for?
Lithium-ion batteries are currently used in most portable consumer electronics such as cell phones and laptops because of their high energy per unit mass relative to other electrical energy storage systems.
4. What is a disadvantage of lithium batteries?
Despite its overall advantages, lithium-ion has its drawbacks. It is fragile and requires a protection circuit to maintain safe operation. Built into each pack, the protection circuit limits the peak voltage of each cell during charge and prevents the cell voltage from dropping too low on discharge.
5. What are 3 important uses of lithium?
The most important use of lithium is in rechargeable batteries for mobile phones, laptops, digital cameras and electric vehicles. Lithium is also used in some non-rechargeable batteries for things like heart pacemakers, toys and clocks.
6. Can lithium-ion batteries be recharged?
Lithium-ion batteries, on the other hand, are rechargeable. We call this type of cell a secondary cell. This means that the lithium ions can move in two directions: from the anode to the cathode while discharging and from the cathode to the anode when recharging.
Lithium batteries feature primary cell construction. This means that they are single-use—or non-rechargeable. Ion batteries, on the other hand, feature secondary cell construction. This means that they can be recharged and used over and over again.
2. What is lithium-ion battery and how does it work?
The anode and cathode store the lithium. The electrolyte carries positively charged lithium ions from the anode to the cathode and vice versa through the separator. The movement of the lithium ions creates free electrons in the anode which creates a charge at the positive current collector.
3. What are lithium-ion batteries used for?
Lithium-ion batteries are currently used in most portable consumer electronics such as cell phones and laptops because of their high energy per unit mass relative to other electrical energy storage systems.
4. What is a disadvantage of lithium batteries?
Despite its overall advantages, lithium-ion has its drawbacks. It is fragile and requires a protection circuit to maintain safe operation. Built into each pack, the protection circuit limits the peak voltage of each cell during charge and prevents the cell voltage from dropping too low on discharge.
5. What are 3 important uses of lithium?
The most important use of lithium is in rechargeable batteries for mobile phones, laptops, digital cameras and electric vehicles. Lithium is also used in some non-rechargeable batteries for things like heart pacemakers, toys and clocks.
6. Can lithium-ion batteries be recharged?
Lithium-ion batteries, on the other hand, are rechargeable. We call this type of cell a secondary cell. This means that the lithium ions can move in two directions: from the anode to the cathode while discharging and from the cathode to the anode when recharging.
