48V Lithium Ion Battery Pack 20kWh Off Grid Solar System Energy Storage with BMS Rack Mounted IP65 Protected CE Certified
- Category: >>>
- Supplier: S K Tech Co. Ltd.
Share on (1600996919785):
Product Overview
Description
Safety: LiFePO4 batteries are known for their excellent thermal and chemical stability. They are less prone to overheating and thermal runaway, making them a safer choice compared to some other lithium-ion chemistries.
Long Cycle Life: LiFePO4 batteries have a long cycle life, which means they can be charged and discharged many times without significant degradation in performance. This makes them suitable for applications where longevity is important.
Fast Charging: High-voltage LiFePO4 batteries can support relatively fast charging, which can be useful in applications where rapid replenishment of energy is required.
Wide Temperature Range: They can operate effectively over a wide temperature range, making them suitable for both high and low-temperature environments.
Long Cycle Life: LiFePO4 batteries have a long cycle life, which means they can be charged and discharged many times without significant degradation in performance. This makes them suitable for applications where longevity is important.
Fast Charging: High-voltage LiFePO4 batteries can support relatively fast charging, which can be useful in applications where rapid replenishment of energy is required.
Wide Temperature Range: They can operate effectively over a wide temperature range, making them suitable for both high and low-temperature environments.
Product Parameters
Module | SW76R82K-H9 | ||
Battery System Capacity (kWh) | 9.216* n | ||
Battery System Voltage (Vdc) | 76.8* n | ||
Battery System Capacity (AH) | 120 | ||
Battery Module | 38.4V240AH | ||
Battery Capacity(kWh) | 9.216 | ||
Battery Modules Qty. (Optional ) | 1~9 | ||
Battery System Charge Upper-Voltage | 86.4* n | ||
Standard Operation Current( A ) | 120 | ||
Normal Operation Current( A) | 120 | ||
Max. Operation Current( A ) | 150 | ||
Battery System Discharge lower-Voltage | 67.2* n | ||
Round-trip efficiency (@0.5C-rate) | 95% | ||
Depth of Discharge | 90% | ||
Dimension(W* D* H, mm) | 551×732.5 ×2270(mm) | ||
Communication | CANBUS/Modbus RTU/TCP/IP | ||
Weight ( kg) | 95kg* n | ||
Operation Life | 15+Years | ||
Operation Temperature | 10~40℃ | ||
Storage Temperature | - 20 ~ 60℃ | ||
Humidity | 5 – 95%(without condensing) | ||
Altitude (m) | <4000 | ||
Product Certificate | IEC62619/CE/UN38 .3 | ||
