0.65x0.65mm OV6948 40 Kpixel sensor medical endoscope camera module led with USB board
0.65x0.65mm OV6948 40 Kpixel sensor medical endoscope camera module led with USB board
0.65x0.65mm OV6948 40 Kpixel sensor medical endoscope camera module led with USB board
0.65x0.65mm OV6948 40 Kpixel sensor medical endoscope camera module led with USB board
0.65x0.65mm OV6948 40 Kpixel sensor medical endoscope camera module led with USB board
0.65x0.65mm OV6948 40 Kpixel sensor medical endoscope camera module led with USB board

0.65x0.65mm OV6948 40 Kpixel sensor medical endoscope camera module led with USB board

Share on (1600999525142):


Price:$300.00 - $430.00

Quantity:


Product Overview

Description


Optical Spec












































Coms size 1/18"
Pixel size720*720P
Fno5.0
Diagonal Fov120 degree
TV-distortion<6%
Relative illumiance60%
Chief ray angle<25%
Maximum image circle1.0 mm
Depth of filed5-100 mm




Electric spec












































Sensor 1/18" 720*720
Max frame rateVGA 360fps
InterfaceUSB 2.0
USB output solutionMJPG 720*720
White balance auto modeAuto mode
Operating temperature-10 ~+50 degree
Steel tube temperature</= 41 degree
Min diameter1.05*1.05 MM
Maximum length2 M










More details for endoscope camera module





OVM 6946 details.jpg
