Singfo Solar mini portable outdoor etfe mobile solar panel foldable 18v 80w solar cell energy charger panels
- Category: >>>
- Supplier: Singfo Solar Energy Ltd.
Share on (1601000076557):
Product Overview
Description
Product Description
Singfo Solar 80w Bend Power Panels Solars Paper Thin Rolling Foldable Customize Flexible Solar Panels Boat
Specification
Electrical Parameters | ||||||||
Model no. | SF3-60WCZD | SF3-80WCZD | SF3-100WCZD | SF3-120WCZD | ||||
Maximum Power/Pmax | 60W | 80W | 100W | 120W | ||||
Maximum Power Voltage(Vmp) | 20V | 20V | 20V | 20V | ||||
Maxium Power Current(Imp) | 3.0 A | 4.0 A | 5.0A | 6.0 A | ||||
Open-circuit Voltage(Voc) | 24V | 24V | 24V | 24V | ||||
Short-circuit Current (Isc) | 3.15A | 4.2 A | 5.25A | 6.3 A | ||||
Dimension （unfolded） | 988*480*25mm | 960*624*25mm | 1230*560*25mm | 1848*480*25mm | ||||
Dimension （folded） | 494*480*35mm | 624*480*35mm | 615*560*35mm | 494*480*45mm | ||||
Net Weight | 2.8Kgs | 3.5Kgs | 4.45Kgs | 5.4Kgs | ||||
Model no. | SF3-160WCZD | SF3-200WCZD | SF3-300WCZD | SF3-400WCZD |
Maximum Power/Pmax | 160W | 200W | 300W | 400W |
Maximum Power Voltage(Vmp) | 20V | 20V/40V | 36V | 40V |
Maxium Power Current(Imp) | 8.0 A | 10.0A/5.0A | 8.33 A | 10.0A |
Open-circuit Voltage(Voc) | 24V | 24V/48V | 43.2V | 48V |
Short-circuit Current (Isc) | 8.4 A | 10.5A/5.25A | 8.75 A | 10.5A |
Dimension (unfolded) | 1788*624*25mm | 2390*564*25mm | 2430*812*25mm | 2370*1074*25mm |
Dimension (folded) | 624*480*45mm | 635*564*45mm | 812*608*45mm | 1074*631*45mm |
Net Weight | 6.8Kgs | 8.4Kgs | 12Kgs | 2.74Kgs |
Project Cases
Guangzhou 3MW
Somalia 5KW
Dubai 78KW
Netherlands 873KW
Company Profile
SINGFO SOLAR, located in Dongguan city was established in 1996 with more than 25 years experience in the energy power industry. It is a new energy high-tech enterprise that integrates R&D production, sales and testing, construction installation and after-sales from solar panel to solar energy system. Specializing in solar photovoltaic production and installation passed with ISO, CE, and TUV certifications, providing a complete one-stop service from component manufacturers to EPC construction general contractors.
