Rating | 3A 240VAC (A300) | ||||||
Operation speed | 0.1mm-0.5m/s | ||||||
Operating frequency | Electical: 30 operations/min | ||||||
Contact rsistance | 25mΩ max. (initial value) | ||||||
Insulation resistance | 100mΩ min. (below 500VDC) | ||||||
Rated insulation voltage(UI) | 400V | ||||||
Dielectric strength | AC2500V/Umip 4KV | ||||||
Vibration | 10~55Hz,1.5mm double amplitude | ||||||
Shock | Mechanical: Approx. 1,000m/s² (Approx. 100G'S)Malfunction: Approx. 300m/s² (Approx 30G'S) | ||||||
Ambient temperature | Using: -20~+70℃ (With no icing) | ||||||
Humidity | <95% RH | ||||||
Electrical life | 150,000 operations above | ||||||
Protection level | IP65 (IEC Standard) | ||||||
