china supplier nylon hose r8 wire high pressure airless paint spray hose
- Category: >>>
- Supplier: Shandong Dijieflex Technology Co. Ltd.
Share on (1601000764658):
Product Overview
Description
Products Description
PAINT-SPARY HOSE
Blasting pressure：500BAR
Safety Factor：2.5：1
Working temperature：-40℃-+93℃
HOSE I.D.：6.3MM
HOSEO.D.：12.2MM
Minimum Order Quantity (MOQ):2000m
Working temperature：-40℃-+93℃
HOSE I.D.：6.3MM
HOSEO.D.：12.2MM
Minimum Order Quantity (MOQ):2000m
Structure
Lining: Polyamide.
Reinforcement: 1 layer of braided synthetic fiber+ l layer of braided steel wire.
Outer layer: Pin pricked anti-abrasion polyurethane.
Temperature range: -40ºC~93ºC.
Reinforcement: 1 layer of braided synthetic fiber+ l layer of braided steel wire.
Outer layer: Pin pricked anti-abrasion polyurethane.
Temperature range: -40ºC~93ºC.
Product Advantages
Features
1. Extremely high working pressure.
2. Durable abrasion resistant outer cover.
3. Significant weight reduction when compared with equivalent rubber hoses.
4. Resistant to ozone, ultraviolet and aging.
5. Outer cover resistance to hydrolysis and microbes.
6. Low permeation rate, High temperature stability, High impulse resistance and long service life.
7. Long lengths of up to 4500 metres available.
8. Lightweight water jetting hose for washdown and offshore jetting applications.
2. Durable abrasion resistant outer cover.
3. Significant weight reduction when compared with equivalent rubber hoses.
4. Resistant to ozone, ultraviolet and aging.
5. Outer cover resistance to hydrolysis and microbes.
6. Low permeation rate, High temperature stability, High impulse resistance and long service life.
7. Long lengths of up to 4500 metres available.
8. Lightweight water jetting hose for washdown and offshore jetting applications.
Certifications
Manufacturer of hydraulic hoses
Our strict process and high quality raw material make it easy to pass ISO 9001 and TS16949 quality system certification.
Recommend Products
Company Profile
Shandong Dijieflex Technology Co. Ltd. is a famous company producing high quality full range of thermoplastic hoses. Our company mainly produces Ultra High Pressure Hose, PTFE Hose, Lubricating Hose, Grease Hose, Paint Spray Hose, TPU Hose, Sewer Cleaning Hose, Test Hose, Jack Hose, Nylon Hose, etc. We not only provide customers with high-reliability and cost-effective standard products,but also continuously develop new products according to the latest requirements of customers to meet the special application requirements of various industries. Our strict process and high quality's raw material make it easy to pass ISO9001 and TS16949 quality system certification. Our company has maintained the strongest competitiveness in new material development and new technology applications.
Exhibition
Product packaging
We have sufficient raw materials to produce all kinds of hydraulic hoses, as well as sufficient stocks of Ultra High Pressure Hose, PTFE Hose, Lubricating Hose, Grease Hose, Paint Spray Hose, TPU Hose, Sewer Cleaning Hose, Test Hose, Jack Hose, Nylon Hose, etc. Fast delivery and good packaging quality.
Quality test: 100% pressure test and leakage test before packing.
Packing details: Standard export packing or according to customer's special requirements.
Delivery Detail: The specific delivery time depends on the items and the quantity.
INCH | HoseI.D | HoseO.D | Working Pressure | Minimum BendRadius | Min.Bend Radius | ||||||||
(MM) | (MM) | (Mpa) | (Bar) | (Psi) | (Mpa) | (Bar) | (Psi) | (mm) | |||||
1/4 | 6.3 | 12.2 | 50 | 500 | 7250 | 125 | 1250 | 18125 | 35 | ||||
5/16 | 8 | 14.2 | 50 | 500 | 7250 | 125 | 1250 | 18125 | 40 | ||||
3/8 | 10 | 16 | 50 | 500 | 7250 | 125 | 1250 | 18125 | 60 | ||||
FAQ
Q1: Are you factory or trading company?
A: We are factory, specialized in hose. Welcome to visit our factory.
Q2: What is your terms of packing?
A: Plastic woven belt, Carton Packaging, Wooden Cases or Your Request
Q3: What is your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q4: What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q5: How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and
the quantity of your order.
Q6: Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q7: What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q8: Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q9: How do you make our business long-term and good relationship?
A: 1.We keep good quality and competitive price to ensure our customers benefit ;
2.We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
A: We are factory, specialized in hose. Welcome to visit our factory.
Q2: What is your terms of packing?
A: Plastic woven belt, Carton Packaging, Wooden Cases or Your Request
Q3: What is your terms of payment?
A: T/T 50% as deposit, and 50% before delivery. We'll show you the photos of the products and packages before you pay the balance.
Q4: What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q5: How about your delivery time?
A: Generally, it will take 30 to 60 days after receiving your advance payment. The specific delivery time depends on the items and
the quantity of your order.
Q6: Can you produce according to the samples?
A: Yes, we can produce by your samples or technical drawings. We can build the molds and fixtures.
Q7: What is your sample policy?
A: We can supply the sample if we have ready parts in stock, but the customers have to pay the sample cost and the courier cost.
Q8: Do you test all your goods before delivery?
A: Yes, we have 100% test before delivery
Q9: How do you make our business long-term and good relationship?
A: 1.We keep good quality and competitive price to ensure our customers benefit ;
2.We respect every customer as our friend and we sincerely do business and make friends with them, no matter where they come from.
